Runtal NEO - 6,780 BTU - Hydronic Fan Assisted Radiator - 23.3" H - 59" W - 4.6" D
Model:
NEO 8-1500
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
- Flexible Output
- With four fan speeds and a wide range of acceptable water temperatures, the NEO 8-1500 can provide anywhere between 1361 BTU and 13,850 BTU and your space, making it easy to stay comfortable through shifting conditions.
- Dual Heat
- The NEO utilizes two separate methods of heat transfer to keep you comfortable. Hydronic heating radiates outward from the unit while the electric heating element provides convective heating that increases the temperature of the air flowing past it.
- Air Filtration
- An included washable filter captures particulates and irritants in your home's air. This means that when the fans are active, the NEO isn't just making your space more comfortable, but is also actively cleaning the air.
- Exceptional Efficiency
- Energy waste is a drain on your wallet that can be avoided with Runtal. Between the flat tube hydronic heat exchanger and the welded-steel construction, Runtal developed a radiator design that transfers the most possible heat into your space.
- Product Includes
- (1) Runtal NEO 8-1500 Hydronic Fan Assisted Radiator
- (1) 24V Transformer Plug
The NEO (New Energies Optimized) fan-assisted radiator is Runtal's latest hydronic heating innovation. The NEO combines a traditional flat-panel hydronic radiator, a small electric heating element, and several 24V fans to produce one of the most effective radiators on the market. The additional heating element and multi-speed fans give the NEO 8-1500 a much higher output than it's compact size would typically allow. these components also mean that a NEO radiator can be used in an assortment of applications where traditional hydronic or electric radiators would not work. If you're looking for a hydronic heating solution that is easy to scale to nealy any space in a variety of climates, the NEO fits the bill.
Product Note
Displayed lead time is for 9010R Runtal White. Orders with other colors are built to order and take four to six weeks to ship out. Built to order products are not eligible for returns, refunds, or cancellations. Heating capacity in BTU and kW is listed for applications with a 140 degree Fahrenheit water temperature and a fan speed of low. For capacity information at different supply temperatures and fan speeds, please consult the Runtal NEO brochure in the manuals tab above. Please specify desired piping configuration when ordering. Piping configurations may also be found in the Runtal NEO brochure.
Specifications
NEO 8-1500
General Information
Type
Fan Assisted
Product Line
NEO
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Connection Type
NPT
Additional Model Numbers
NEO 8-1500-9010R, NEO 8-1500
Performance
Heating BTU
7000
Heating Capacity
6780 BTU
Heating Capacity (kW)
1.987 kW
Electrical Data
Voltage
110 Volts
Dimensions
Supply Connection
1/2 Inch
Return Connection
1/2 Inch
Product Height
23 7/24 Inches
Product Width
59 Inches
Product Depth
4 29/48 Inches
Product Weight
94.5 Pounds
Certifications
Country of Origin
United States
Warranty Information
Warranty
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
