Aspen Mini White - Mini Split Condensate Pump Kit - Universal Voltage - Up to 54,000 BTU/hr

Model:

ASP-MW-UNI

Write A Review
$284.92
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Monday, Dec 23rd
Shipping to60601
synchrony card logo
$48 / Month
Suggested monthly payments with 6 month financing.
Aspen Mini White - Mini Split Condensate Pump Kit - Universal Voltage - Up to 54,000 BTU/hr
Aspen Mini White - Mini Split Condensate Pump Kit - Universal Voltage - Up to 54,000 BTU/hr
Model: ASP-MW-UNI
$284.92
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    A properly functioning mini split system requires an installation that allows for proper condensate drainage. Condensate removal pumps are used in situations where gravity draining is not an option. If you're using a high wall system, ducted or free-standing units, you may need an ultra-quick alternative to expel water that has been removed by the cooling system. Aspen's ASP-MW-230 Mini White Condensate Pump is a compact and discrete pump, designed for great performance and easy maintenance. Aspen's ASP-MW-230 is perfect for applications where easy access to the reservoir for future maintenance is key. Plus, this unit is so small and quiet, you'll never even know it's there.
  • Designed for Versatile Installation
  • Aspen Mini Split Condensate Pump Kits like the ASP-MW-UNI are designed to not only be the ultra-quick fix for your air conditioning set up, but also to focus on reliability with an anti-siphon device to keep air from causing priming issues.
  • Performance that Packs a Punch
  • The ASP-MW-UNI has a max flow rate of 3 GPM that'll keep your system running smoothly. Each unit also features an anti-siphon device that makes sure your pump is always primed, keeping air from leaking in and causing problems.
  • Universal Voltage
  • The Aspen ASP-MW-UNI Mini White is compatible with all voltages allowing for an easy integration into your existing components.
  • Product Includes
  • (1) Anti siphon device
  • (1) Drain connector kit
  • (1) Fixing kit
  • (1) Install manual
  • Product Note
    The Aspen ASP-MW-UNI is suitable for use with domestic high wall mounted mini split systems. The ASP-MO-UNI is a compact condensate pump designed for installation below the wall mounted unit, where easy access for maintenance is key. Requires 1/4" ID X 3/8" OD Tubing

Specifications

ASP-MW-UNI
specs product image PID-31127
Overview
Product Category
Mini Split Accessories
UPC
10021449839393
General Information
Type
Condensate Pump
Product Line
Mini White
Product Category
Mini Split Accessories
Application
Surface
Performance
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
54000 BTU
Maximum Head
32.81 Feet
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
21 dB
Condensate Removal Rate
3 GPH
Electrical Data
Current Draw
0.1 Amps
Dimensions
Product Height
4 25/48 Inches
Product Width
7 2/12 Inches
Product Depth
2 2/12 Inches
Product Weight
1.01 Pounds
Certifications
Country of Origin
UK
CSA Listed
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
