Features
- Thermoglaze Enamel Interior
- The Buderus SU100/5W indirect fired water heater is coated internally with Buderus' Thermoglaze enamel, protecting the inside of the tank from corrosion.
- Included Anode Rod
- The water heater includes a sacrificial, replaceable anode rod, significantly reducing pipe corrosion over time.
- Large Cleaning Port
- The SU100/5W has a large port for cleaning the internals of the tank, simplifying a normally difficult task.
- Included Leveling Legs
- Included with the water heater are a set of adjustable legs, allowing the water heater to remain level even on inclined surfaces.
Buderus single coil indirect fired hot water heaters are built with the quality and durability needed to last your home for many years. An aesthetic white coating allows the water heater to blend in with any utility room, while the patented thermoglaze interior keeps internal corrosion at bay. An included magnesium anode rod extends the service life of the water heater by a factor of years by further reducing corrosion. Screw-on feet allow for easy leveling of the tank even on slightly inclined surfaces, while top-side connections make boiler connection easy.
Specifications
SU100/5W
Overview
Product Category
Water Heater - Indirect-Fired
General Information
Type
Indirect Water Heater
Product Line
SU
Product Category
Water Heater - Indirect-Fired
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
1
Application
Residential
Capacity
103 Gallons
Performance
First Hour Delivery
First Hour Delivery
Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
281 Gallons
Continuous Recovery Rate
209 Gallons
Dimensions
Cold Water Inlet
1 Inch
Hot Water Outlet
1 Inch
Boiler Supply
1 Inch
Boiler Return
3/4 Inch
Product Height
72 1/4 Inches
Product Width
26 3/8 Inches
Product Depth
26 3/8 Inches
Product Weight
263 Pounds
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
8 Years
