Features
- Hydrastone Lining
- The 1/2" Hydrastone tank liner, made from a material similar to cement, protects the tanks from corrosion. When water enters the tank, it's absorbed into the Hydrastone lining and loses it's oxygen, becoming non-corrosive.
- Burnham Control Compatible
- Alliance SL indirect-fired water heaters are designed to work with Burnham's proprietary controls systems, IQ and Sage2.3. These systems can prioritize the Alliance SL over space heating and modify the water temperature for ideal recovery rates.
- Minimal Maintenance
- With the seamless, no-weld construction of the AL80LT, there is no need for an anode rod, reducing maintenance.
- Cold Water Diffuser
- A cold water diffuser in the tank prevents cold water from being introduced to hot water. This improves the output of the water heater.
- Product Includes
- (1) Burnham AL70CSL Indirect Water Heater
- (1) TPI Thermostat Control Module
Burnham is devoted to pushing the limits of heating technology and efficiency. Their ingenuity is responsible for some of the most efficient products on the market today. The Alliance SL is Burnham's foray into indirect-fired water heating. Using your boiler as a heat source means that the recovery rate of Alliance SL models is superior to that of standard direct-fired or electric water heaters. In addition to efficiency, the Alliance SL is also designed for simplicity. All connections are easily accessible at the top of the tank, where the heat exchanger is mounted. By mounting the heat exchanger here, it may be serviced without draining the tank. Easy to install, easy to service, and energy efficient, the commercial AL70CSL is the perfect water heating solution for any application.
California residents see
Warning: This product can expose you to chemicals including Chromium (hexavalent compounds) which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
AL70CSL
Overview
Product Category
Water Heater - Indirect-Fired
UPC
672616778040
General Information
Type
Indirect Water Heater
Product Line
Alliance SL
Product Category
Water Heater - Indirect-Fired
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
1
Application
Residential
Connection Type
Union
Material
Hydrastone-Lined
Capacity
70 Gallons
Performance
First Hour Delivery
First Hour Delivery
Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
400 Gallons
Continuous Recovery Rate
840 Gallons
Dimensions
Cold Water Inlet
1 Inch
Hot Water Outlet
1 Inch
Supply Connection
1 1/2 Inches
Return Connection
1 1/2 Inches
Product Diameter
28 Inches
Product Height
45 3/4 Inches
Shipping Weight
290 Pounds
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Vessel Warranty
10 Years
Reviews
Burnham AL70CSL Reviews & Ratings
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Please share your insights with fellow shoppers.
Product Q&A
Be the First to Ask A Question
Answered by Ken, the eComfort Product Expert
How-To Articles
What Size Tankless Water Heater Do I Need
Size matters when it comes to your tankless water heater. In fact, it is t...
Signs You Need a New Water Heater
You’ve heard the stories. A 60-gallon hot water heater tank ruptures, flo...
An Intro to Indirect Water Heaters
If you heat your home with a boiler, you have the opportunity to get the most e...
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Burnham AL70CSL - 70 Gallon - Indirect Water Heater
