Features
- Two Inch Thick Insulation Layer
- Crown's Maxi-Therm heaters are lined with a two inch thick layer of insulation, keeping the water in your water heater hot for hours on end during standby periods.
- Rugged Steel Tank
- The outer shell of the Maxi-Therm tank is constructed from high grade steel, a material proven in thousands of installations to be durable and efficient.
- Three Sacrificial Anode Rods
- The Maxi-Therm water heater comes with three replaceable sacrificial anode rods, dramatically increasing the longevity of the water heater by removing corrosive materials before they can cause damage..
- Porcelain Enamel Coated Coil
- The coil on the inside of the Maxi-Therm water heater is coated with a porcelain enamel, working with the anode rods to prevent corrosion.
The Maxi-Therm indirect fired hot water heater from Crown is designed from the ground up to maximize longevity in every way possible. Both the tank and the internal coil are coated with a porcelain enamel, preventing corrosive materials in a home's water supply from reacting with the metals within the water heater. The tank also contains three sacrificial anode rods, reactive rods that descend into the tank and neutralize corrosives before they have a chance to damage your water heater. Combined with two inches of CFC-free foam insulation all around the tank, the Maxi-Therm is an ideal long term water heater solution.
California residents see
Warning: This product can expose you to chemicals including Chromium (hexavalent compounds) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
MT065GBR
General Information
Type
Indirect Water Heater
Product Line
Maxi-Therm 2
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
1
Connection Type
NPT
Material
Stainless Steel
Performance
First Hour Delivery
First Hour Delivery
Sometimes called First Hour Rating, this is the number of gallons of hot water the heater can supply per hour when starting with a fully heated tank. The recovery of the water heater depends on your boiler's BTU and boiler output temperature.
204 Gallons
Continuous Recovery Rate
162 Gallons
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Storage Volume
60 Gallons
Cold Water Inlet
1 Inch
Hot Water Outlet
1 Inch
Supply Connection
3/4 Inch
Return Connection
3/4 Inch
Product Diameter
22 Inches
Product Height
60 Inches
Shipping Weight
196 Pounds
Certifications
Country of Origin
United States
ETL Listed
Yes
AHRI Certified
Yes
Warranty Information
Vessel Warranty
10 Years
Reviews
Crown Boiler Co. MT065GBR Reviews & Ratings
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Please share your insights with fellow shoppers.
How-To Articles
What Size Tankless Water Heater Do I Need
Size matters when it comes to your tankless water heater. In fact, it is t...
Signs You Need a New Water Heater
You’ve heard the stories. A 60-gallon hot water heater tank ruptures, flo...
An Intro to Indirect Water Heaters
If you heat your home with a boiler, you have the opportunity to get the most e...
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Crown Boiler MT065GBR - 60 Gallon - Indirect Water Heater
