Daikin - 15k BTU - Ceiling Cassette - For Multi-Zone - Grille Sold Separately
Model:
FFQ15Q2VJU-NG
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
- Daikin 3MXS24NMVJU / 3MXL24QMVJU Outdoor Condenser Unit
- Daikin 4MXS36NMVJU Outdoor Condenser Unit
- Daikin RMXS48LVJU Outdoor Condenser Unit
- Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
- Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing..
- Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
This product requires a compatible outdoor condenser for functionality.
Daikin has firmly established themselves as a world leader in heating and cooling equipment manufacturing, and their ductless systems are no exception. This is a FFQ15Q2VJU ceiling cassette indoor unit for use in building a multi-zone mini split system. Whisper quiet operation means that the unit will never draw attention to itself, and sleek aesthetics allow the unit to blend into almost any home decoration theme. Daikin indoor units posess powerful energy saving features, which when combined with Daikin's extensive experience with building efficient units provides a cost-conscious solution to any home's heating and cooling needs.
Product Features
Whisper Quiet Operation
Daikin ductless units are engineered from the ground up for impressively quiet operation. The solidness of the units construciton works together with quiet motor operation to make the unit as unobtrusive as possible to its surrounding environment.
Inverter Technology Prevents Temperature Fluctuation
Daikin ductless units come equipped with inverter technology. This technology works together with the expansion valve to adjust coolant flow rate and compressor speed on the fly to match indoor conditions. This results in less dramatic indoor temperature swings, which in turn results in a more comfortable home.
Built-In Advanced Filtration System
Daikin mini splits do more for your home's comfort level than control its temperature. An advanced microbial filtration system is installed in the indoor unit, allowing the mini split to purify your home's air as well as heating or cooling it.
Product Compatibility
Product Note
This product requires a compatible Daikin outdoor condenser and the following accessories for installation:
eComfort.com Note
The remote control(s) for this product need(s) to be purchased separately. See Accessories tab above.
California residents see
Warning: This product can expose you to chemicals including Formaldehyde (gas) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
FFQ15Q2VJU-NG
General Information
Type
Ceiling Cassette
Product Line
MXS
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Remote Control
Not Included
Indoor Unit Size(s)
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
15
Installation Location
Indoor
Grille
Included
Performance
Cooling BTU
15000
Cooling Capacity
15000 BTU
Maximum Air Flow
424 CFM
Minimum Air Flow
283 CFM
Minimum Sound Level
31.5 dB
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
42.5 dB
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
1/2 Inch
Liquid Connection Size
1/4 Inch
Condensate Drain Size
1 1/24 Inches
Product Height
11 1/4 Inches
Product Width
22 5/8 Inches
Product Depth
22 5/8 Inches
Product Weight
48 Pounds
Certifications
Country of Origin
Japan
ETL Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
