Features
Please Note: Due to the limited availability of this model, these products will be sold in systems only. Should you have any questions please contact our sales center for alternate options.
California residents see
Warning: This product can expose you to chemicals including Formaldehyde (gas) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
FTX24NMVJU
General Information
Type
Wall Mounted
Product Line
19-Series
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
No
Refrigerant Type
R-410A
Remote Control
Wireless
Indoor Unit Size(s)
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
24
Installation Location
Indoor
Performance
Cooling BTU
24000
Cooling Capacity
24000 BTU
Moisture Removal
9.6 Pints/Hour
Maximum Air Flow
745 CFM
Minimum Air Flow
403 CFM
Minimum Sound Level
34 dB
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
53 dB
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
5/8 Inch
Liquid Connection Size
1/4 Inch
Condensate Drain Size
11/16 Inch
Product Height
11 5/8 Inches
Product Width
39 Inches
Product Depth
10 1/3 Inches
Product Weight
26 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Reviews
(8)
Daikin FTX24NMVJU Reviews & Ratings
Good quality and very very quiet
By Thomas M.
Remer, Minnesota
Purchased 04/01/2020 |
Review Posted 05/15/2020
Installed in one of our rental cabins at our resort. Quiet, efficient works well. Second Daikin we have installed at the resort and we are very satisfied. We will be staying with the Daikin brand for our next installs. Controls our a bit simpler than the last one which is good given multiple people will be using the remote. My extensive research showed that Daikin was one of the better quality brands.
Thomas M. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Loving My Purchase
By Arley H
INOLA, Oklahoma
Purchased 05/31/2019 |
Review Posted 06/28/2019
I spent over a month looking at different mini splits, I kept getting drawn back to this one. Soon I found myself comparing each other one to this one. So between the customer service I was getting from eComfort with my questions and what I was reading about Daikin I knew it was the right choice. It was installed in my office in my shop,it cools so well that I am leaving window open to the shop to offset the cooling there. No regrets at this time.
Arley H Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Great Quiet Unit!!!
By John V
GLENDALE, New York
Purchased 04/08/2019 |
Review Posted 05/07/2019
This Daikin Inverter with it's matching Condenser works like a charm! The unit is EXTREMELY quiet on the INSIDE and Outside! eComfort answered all my questions before and during my purchase with the utmost Professionalism! Have placed 3 orders with them already! Can't wait to order the wireless controller for this unit so I can control it thru my mobile phone! Thanks eComfort!!
John V Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Price, Light Weight, I'd Buy It Again
Very happy with my new heat pump!
By Rosita A
Portland, Oregon
Purchased 12/17/2018 |
Review Posted 01/31/2019
Only expected this to heat the living room, but it's done a great job of spreading heat throughout the whole house! Very pleased. Still waiting to see my first electric bill, so will update this if it's higher than expected, but very happy so far!
Rosita A Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
5/5
5/5
My heat pump unit is all I expected it to be!
By Craig D
Port Angeles, Washington
Purchased 06/21/2018 |
Review Posted 08/27/2018
My heat pump unit is all I expected it to be - Thanx for the quality product
Craig D Recommends This
Was this review helpful?
Rating Breakdown
3/5
4/5
4/5
4/5
Pros:
Easy To Use, Quiet, High Quality
Just what I needed
By Joe L
Calhoun, Louisiana
Purchased 07/04/2018 |
Review Posted 08/16/2018
This complete unit and all the accessories in the starter kit were exactly what I needed. I’m conditioning a 32 x 24 foot shop to reduce the humidity and stop the sweating of all my tools. It’s doing an excellent job of removing the moisture. I have the drain from the evaporator running into a 5 gallon bucket and in the Dry Mode I’m getting about 2 gallons of water a day. It keeps the shop at 75 degrees and it has been in the middle to upper 90’s here. The shop is foam insulated. Will have to see how much it raises my electric bill.
Joe L Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Excellent for my shop
By Keith M
Conroe, Texas
Purchased 07/15/2018 |
Review Posted 08/06/2018
It cooled my 1000 sq ft shop that is lightly insulated in 98 deg heat down to 65 deg.
Keith M Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Home owner
By Bobby L.
Utica, Kentucky
Purchased 03/15/2018 |
Review Posted 04/06/2018
The unit was easy to install and set up. Operation is super quiet inside and out.
Bobby L. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
How-To Articles
eComfort Boosts Comfort and Energy Savings at Historic Home
Owning a historic home can be very rewarding. But those rewards come with respo...
How to Pick the Perfect Mini Split Suspended Indoor Unit
A ceiling-suspended mini split is the perfect ductless solution for large open ...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Daikin 19 Series 24k BTU - Wall Mounted Unit - For Single-Zone
