Fantech DBF4XLT
Fantech DBF4XLT
Hover to zoom
1 of 1

Fantech DBF - Dryer Booster Kit - Up to 130 ft - Wall Mount Indicator Panel

Model:

DBF4XLT

Write A Review
$310.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Wednesday, Apr 2nd
Shipping to43085
synchrony card logo
$52 / Month
Suggested monthly payments with 6 month financing.
Fantech DBF - Dryer Booster Kit - Up to 130 ft - Wall Mount Indicator Panel
Fantech DBF - Dryer Booster Kit - Up to 130 ft - Wall Mount Indicator Panel
Model: DBF4XLT
$310.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Optional Accessories 1
$98.00

Features

    Constructed with a galvanized steel housing housing, the Fantech DBF 4XLT Dryer Booster Kit uses a 170 CFM fan to support up to 130 feet of dryer duct run. It is specifically designed with backward inclined blades to allow lint to easily pass through the fan and features an indicator panel displaying the fan's status. The DBF 4XLT features an automatic pressure sensing switch which automatically activates the fan when the dryer comes on. Dryer booster fans allow you to exhaust dryer fumes through extended ventilation.
  • Backward Inclined Blades
  • Backward inclined blades allow particles to easily pass through the fan blades preventing a build-up.
  • Automatic Pressure Sensing Switch
  • The switch directs power to the fan in five minute cycles providing a continuous boost when the fan is operating.
  • Indicator Panel
  • An LED light indicates when the fan is working properly.
  • Product Includes
  • FG 4XL Inline Fan

Specifications

DBF4XLT
specs product image PID-31290
Overview
Product Category
Fans
UPC
650737125400
General Information
Type
Dryer Boosters
Product Line
DBF
Product Category
Fans
Performance
Maximum Air Flow
170 CFM
Duct Run
130 Feet
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Dimensions
Duct Connection
4 Inches
Product Diameter
9 3/4 Inches
Product Height
8 15/16 Inches
Product Weight
8 Pounds
Shipping Height
11 Inches
Shipping Width
13 Inches
Shipping Length
13 Inches
Shipping Weight
10 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years

Reviews

(5)
Fantech DBF4XLT Reviews & Ratings
Verified Buyer
Verified Buyer
Dryer fan
By Wallace D.
Maryville, Illinois
Purchased 08/18/2016 |
Review Posted 09/27/2016
Bought to replace S&P dryer booster fan. Much, much quieter. My S&P fan lasted almost two years. I'm hoping for much more from this fantech.
Wallace D. Recommends This
What's a Related Review? Learn More
Related Reviews
*Related reviews were originally written for products that are very similar to this one. While the reviewed product may differ in color, size, fuel type, or another aspect, we believe it is applicable to this model.
This review was originally written for the DBF4XL.
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Verified Buyer
Verified Buyer
business owner
By Mark H
IL
Review Posted 12/22/2014
Great product but found the pressure sensor only works if the world is working perfectly! Meaning the venting must be in excellent shape and does not come apart in the walls or the power is a reliable source. This was installed in one of our customer's homes. Installation straight forward and worked well but then it became a nightmare. Multiple calls back and a real money looser.

We put it to bed by bypassing the pressure switch (and installed a voltage sensor on the electric clothes dryer cord. Booster now comes on when it senses voltage, off if it doesn't. The booster has to be installed correctly. The sensitivity adjustment screw was on one side under a plate. Our particular installation required this plate to be against a wall in the attic. When we where fighting the sensitivity it required complete removal of booster to access screw.

We feel the product is great but save yourself time & money use a voltage sensor switch to activate booster your bottom line will be better and it will work great!
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Verified Buyer
Verified Buyer
dbf4xl dryer booster vent
By Randy
IL
Review Posted 10/17/2014
purchased, delivered installed myself hooked up works great
What's a Related Review? Learn More
Related Reviews
*Related reviews were originally written for products that are very similar to this one. While the reviewed product may differ in color, size, fuel type, or another aspect, we believe it is applicable to this model.
This review was originally written for the DBF4XL.
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Verified Buyer
Verified Buyer
homeowner
By wayne a.
IL
Purchased 08/01/2014 |
Review Posted 08/15/2014
Product received. Customer service was top cabin!
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Clothes Dryer
By Acoolguy
IL
Review Posted 03/14/2014
Best in the market. Customers very happy. Solved the problem.
What's a Related Review? Learn More
Related Reviews
*Related reviews were originally written for products that are very similar to this one. While the reviewed product may differ in color, size, fuel type, or another aspect, we believe it is applicable to this model.
This review was originally written for the DBF110.
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker

Product Q&A

(1)
Expert avatar photo
Product Questions Answered by Ken, the eComfort Product Expert
When the dryer is running does the booster fan run continuous?
Toby
from California
December 23, 2015
