Fantech Fit® - 106 CFM - Low Profile Energy Recovery Ventilator (ERV) - Side Ports - 5" Duct - Exhaust

Model:

FIT 120E

Write A Review
$810.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Monday, Nov 25th
Shipping to60601
synchrony card logo
$135 / Month
Suggested monthly payments with 6 month financing.
Fantech Fit® - 106 CFM - Low Profile Energy Recovery Ventilator (ERV) - Side Ports - 5
Fantech Fit® - 106 CFM - Low Profile Energy Recovery Ventilator (ERV) - Side Ports - 5" Duct - Exhaust
Model: FIT 120E
$810.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Fantech Fit® 120E Fresh Air Appliance is an Energy Recovery Ventilator (ERV) that provides a continuous supply of fresh air while exhausting stale air from your home. ERVs make your heating and cooling systems more efficient by transferring heat and humidity between fresh and stale air during ventilation. With a profile only 8.75" high, the Fit® 120E is ideal for applications with little mechanical room or where it must be located over a false ceiling.
  • Slim Profile
  • The compact design of the Fit® 120E, at only 8.75 tall
  • Easy Maintenance
  • You have easy access to the internal components by unlatching the 4 latches and removing the housing. Each serviceable internal component is easily accessible and can be fully removed.
  • No Drain Required
  • A drain is not required with the Fit® 120E. Moisture in the incoming air is simply transferred to the outgoing air during the circulation process.

Specifications

FIT 120E
specs product image PID-82057
Overview
Product Category
Energy Recovery Ventilators (ERVs)
UPC
650737449407
Additional Model Numbers

FIT120E, FIT 120E

General Information
Type
ERV
Product Line
Fit
Product Category
Energy Recovery Ventilators (ERVs)
Defrost Type Learn More
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Exhaust
Port Location
Side
Housing Material
Galvanized Steel
Performance
Maximum Air Flow
106 CFM
Electrical Data
Power Consumption
170 Watts
Phase
1
Frequency
60 Hz
Current Draw
1.4 Amps
Dimensions
Duct Connection
5 Inches
Product Height
8 3/4 Inches
Product Width
30 1/2 Inches
Product Depth
19 Inches
Product Weight
42 Pounds
Shipping Weight
52 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
