Fantech HERO - 118 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 5" Duct - Recirculation Defrost
Model:
HERO 120H
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
5
$45.00
Only 1 In-Stock
Model: ECO-TOUCH IAQ
$137.80
In-Stock
Model: RTS2
$18.98
Model: RTS5
$35.00
Model: MDEH1
$26.00
In-Stock
Features
- Exceptional Efficiency
- The Fantech HERO is capable of extracting up to 80% of the heat from the air exiting your home, which is then used to temper the fresh air coming in. With efficiency like that, the Fantech HERO will be your hero!
- Healthier Home
- Without proper ventilation, you are subject to indoor air pollutants like chemical products, pet dander or building materials. With an HRV, your home will be ventilated up to 20 times per day, making for a healthier home.
- Winterguard™
- A built-in recirculating defrost system allows for consistent, reliable operation during the winter months.
- Washable Electrostatic Filters
- Easily washable, these filters can be used throughout the life of the HERO. With the integrated MERV 8 filter, you will have exceptional filtration.
- Easy Maintenance and Service
- An access panel on the HERO allows for simple maintenance and serviceability. The core easily slides out with a 12" clearance for additional service ease.
- Insulated Cabinet
- The 24 gauge galvanized steel cabinet is insulated with 3/4" high density expanded polystyrene.
- Product Includes
- HERO 120H HRV
- Wall Mounting Speed Bracket
The Fantech HERO 120H Heat Recovery Ventilator (HRV) is a 118 CFM heat recovery ventilator with top ports and recirculation defrost capabilities. The HERO 120H is a 120 volt unit designed with 4 ports with 5" ducts. HRVs make your heating and cooling systems more efficient by transferring heat between fresh and stale air during ventilation. Its compact size and wall bracket make this HRV easy to mount. The HERO 120H Heat Recovery Ventilator (HRV) features a counterflow core and washable electrostatic filters.
Specifications
HERO 120H
Overview
Product Category
Heat Recovery Ventilators (HRVs)
UPC
650737994006
General Information
Type
HRV
Product Line
HERO
Product Category
Heat Recovery Ventilators (HRVs)
Defrost Type
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Recirculation
Ports Quantity
4
Port Location
Top
Performance
Maximum Air Flow
118 CFM
Apparent Sensible Effectiveness
86 %
Sensible Recovery Efficiency
80 %
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Duct Connection
5 Inches
Product Height
24 1/4 Inches
Product Width
23 1/4 Inches
Product Depth
11 1/2 Inches
Product Weight
41.4 Pounds
Shipping Height
24 1/4 Inches
Shipping Width
23 1/4 Inches
Shipping Length
11 1/2 Inches
Shipping Weight
47 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
Reviews
(4)
Fantech HERO 120H Reviews & Ratings
Clean Air
By Pete C
Michigan
Purchased 01/20/2024 |
Review Posted 02/24/2024
This HRV has made a huge difference for our family. We live in a northern climate, and the humidity was too high in our house during the winter. Condensation was forming on the windows and rotting them out. This machine lowered the humidity levels and made the air in the house noticeably cleaner and easier to breathe.
It is quiet enough and was not a problem to install. Would have been nice if they included some low voltage cable for the controller. I found the 5 inch ports awkward as flexible ducting comes in either 4 or 6 inch, but it worked out.
It is quiet enough and was not a problem to install. Would have been nice if they included some low voltage cable for the controller. I found the 5 inch ports awkward as flexible ducting comes in either 4 or 6 inch, but it worked out.
Pete C Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
4/5
5/5
Pros:
Easy To Use, I39d Buy It Again, Light Weight
Quiet And Well Built
By John P
Walden, New York
Purchased 07/06/2020 |
Review Posted 09/10/2020
I like the unit, whisper quiet. Easy to put in. Works exactly as it should. Sturdy. Don't like that it didn't come with a controller for the price tag. Other than that so far so good.
John P Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Pros:
Features, Easy To Use, Quiet, Light Weight
Cons:
Expensive
Hero
By William M
Winhall, Vermont
Purchased 05/17/2020 |
Review Posted 06/30/2020
Very easy to set up and balance. Very quiet. Great HRV.
William M Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
Pros:
Easy To Use, Quiet, High Quality
Great HRV for the price
By Adam M.
Post Falls, Idaho
Purchased 11/03/2019 |
Review Posted 02/29/2020
We have installed our HRV and have been please with it so far.
We think that for the price compared to other systems and the efficiency of the unit it is a good value.
The only thing that would be nice is if they offered an option for which side on top the ports could be located.
We had a tight install location and the porting of the out door ducts and indoor ducts would have been better if located on opposite side of the unit.
Just would have made it easier and less bends in the ducting, but overall very pleased.
We think that for the price compared to other systems and the efficiency of the unit it is a good value.
The only thing that would be nice is if they offered an option for which side on top the ports could be located.
We had a tight install location and the porting of the out door ducts and indoor ducts would have been better if located on opposite side of the unit.
Just would have made it easier and less bends in the ducting, but overall very pleased.
Adam M. Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
5/5
5/5
