Fantech RE 409 CFM Exterior Duct Fan Roof Mount 8" Duct

Model:

RE8XL

Write A Review
$350.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 7-14 Business Days
synchrony card logo
$59 / Month
Suggested monthly payments with 6 month financing.
Fantech RE 409 CFM Exterior Duct Fan Roof Mount 8
Fantech RE 409 CFM Exterior Duct Fan Roof Mount 8" Duct
Model: RE8XL
$350.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Featuring a galvanized steel housing, the Fantech RE 8XL Centrifugal Exterior Duct Fan is the perfect solution for direct through-ceiling ventilation with quiet operation. This 115 volt model can produce a maximum airflow of up to 409 CFM. The RE 8XL is constructed with an 8" round duct. RE Series fans are designed for residential use. RE fan motors mount on flat or pitched rooftops and can operate with air temperatures up to 140 degrees Fahrenheit. RE models are designed with a flat base for direct flashing to the roof.
  • Permanently Lubricated Sealed Ball Bearings
  • Permanently lubricated sealed ball bearings extend the service life of your fan.
  • Thermal Overload Protection
  • Thermal overload protection automatically resets the fan when temperatures get too high, avoiding potential damage to the unit due to overheating.
  • 100% Speed Controllable
  • On-demand ventilation and precision balancing of systems is controllable through voltage reduction.
  • External Rotor Motor
  • An external rotor motor allows the fan to operate in high-moisture or dust-laden areas.

Specifications

RE8XL
specs product image PID-31252
Overview
Product Category
Fans
UPC
650737420802
General Information
Type
Exterior Duct Fan
Product Line
RE
Product Category
Fans
Mount Type
Roof
Housing Material
Galvanized Steel
Performance
Maximum Air Flow
409 CFM
Maximum Sound Level Learn More
Maximum Sound Level
The sone is a unit of loudness, or how loud a sound is perceived. For reference, the loudness of rustiling leaves is around 0.02 sones, a quiet running refrigerator is around 2 sones, and a running car is around 4-16 sones.
8.9 Sones
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Current Draw
1.4 Amps
Dimensions
Duct Connection
8 Inches
Product Height
5 15/16 Inches
Product Width
20 Inches
Product Length
20 Inches
Product Weight
19 Pounds
Shipping Height
13 Inches
Shipping Width
25 Inches
Shipping Length
25 Inches
Shipping Weight
19 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
