Fantech VHR 120R
Fantech VHR 120R
Fantech VHR 120R
Hover to zoom
1 Of 5
Fantech VHR 120R
Fantech VHR 120R

Fantech VHR - 120 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 6" Duct - Recirculation Defrost

Model:

VHR 120R

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Fantech VHR - 120 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 6
Fantech VHR - 120 CFM - Heat Recovery Ventilator (HRV) - Top Ports - 6" Duct - Recirculation Defrost
Model: VHR 120R
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Fantech VHR120R is a 119 CFM heat recovery ventilator with top ports and exhaust defrost capabilities. The VHR120R is a 120-volt unit designed with 4 ports and 6" ducts. HRVs make your heating and cooling systems more efficient by transferring heat between fresh and stale air during ventilation. Its compact size makes this HRV easy to mount. The VHR120R features an aluminum core, washable electrostatic filters and internal recirculation defrost.
  • Heat Recovery Core
  • An aluminum heat recovery core provides improved heat transfer capacity while taking up less space than traditional cores. Fantech designs their heat recovery cores to withstand drastic temperature variations.
  • Winter Guard™ Defrost
  • The recirculation defrost sequence automatically adjusts based on operating conditions without depressurizing your home, allowing for a smooth transition between Ventilation and Defrost mode.
  • Controls
  • An External rocker switch featuring three positions (Low/Stand By/Medium) that allows for simple control of air flow.
  • Washable Electrostatic Filters
  • Easily washable, these filters can be used throughout the life of the VHR 120R.
  • Easy Maintenance and Service
  • An access panel on the VHR 120R allows for simple maintenance and serviceability.
  • Insulated Cabinet
  • The 24 gauge galvanized steel cabinet is insulated with 1" high density expanded polystyrene. It also has a baked power coated paint for exceptional adhesion and resistance.
  • Product Includes
  • (4) Mounting Bolts

Specifications

VHR 120R
specs product image PID-83353
General Information
Type
HRV
Product Line
VHR
Defrost Type Learn More
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Recirculation
Port Location
Top
UPC
650737957612
Performance
Maximum Air Flow
143 CFM
Apparent Sensible Effectiveness
86 %
Minimum Air Flow
83 CFM
Sensible Recovery Efficiency
77 %
Electrical Data
Voltage
120 Volts
Power Consumption
140 Watts
Phase
1
Frequency
60 Hz
Current Draw
1.3 Amps
Dimensions
Duct Connection
6 Inches
Product Height
26 3/16 Inches
Product Width
23 3/4 Inches
Product Depth
14 1/8 Inches
Product Weight
58.2 Pounds
Shipping Height
28 Inches
Shipping Width
26 Inches
Shipping Length
17 Inches
Shipping Weight
62 Pounds
Certifications
Energy Star Listed
Yes
CSA Listed
Yes
HVI Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
