Goodman AHVE - 3.0 Ton - Air Handler - Horizontal-Discharge - 115/1/60 - Variable Speed ECM Blower with EEV - R-32
Model:
AHVE36CP0300
+
Share This Product
Recommended Accessories

Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
7
Voltage
$153.00
$94.00
In-Stock
Model: UC18S15-24B
$139.00
Factory-Direct
Model: UC18S15-24
$112.00
Factory-Direct
$96.00
In-Stock
Model: DFKE-02
$62.00
$110.00
Features
- Internal Electronic Expansion Valve
- The AHVE has a factory-installed internal electronic expansion valve. This streamlines installation and maintains ideal refrigerant flow for your system.
- Energy Efficient Circulation
- By scaling the airflow to the unique demands and challenges of your home, the advanced variable speed blower motor in the AHVE provides ideal airflow through shifting conditions in nearly any application.
- All-Aluminum Evaporator Coil
- Goodman's evaporator coils use a reliable all-aluminum design featuring fins and grooved tubes. This design maximizes surface area and optimizes heat transfer for efficient comfort.
- SmartFrame™
- This air handler features a rigid SmartFrame™ sub-structure for enhanced accessibility. It provides tool-less access to the filter rack and includes a coil mounting track that improves installation speed for all four compatible orientations.
- Condensate Management
- The AHVE includes a DecaBDE-free thermoplastic drain pan with secondary drain connections, these elements help prevent the formation of condensation and keep your system running smoothly.
- Secure Cabinet
- This air handler enjoys reduced noise levels, less than 2% air leakage, and enhanced durability as a result of its insulated, leather grain embossed cabinet finish.
- Extended Warranty
- Goodman offers a 10-year limited parts warranty when you register your product online within 60 days of installation. An unregistered product has the standard 5-year warranty. See warranty sheet under the "Manuals" tab for more information.
Goodman's AHVE air handler provides effective air distribution for homes of nearly all shapes and sizes. It includes a newly redesigned all-aluminum evaporator coil, thermoplastic drain pan, variable speed fan motor, and Electronic Expansion Valve or (EEV) for short. These cutting-edge components improve the efficiency of your system and the consistency of your comfort. The AHVE air handler also can be mounted in a horizontal or vertical configuration. If you are looking for perfect air circulation, look no further than the AHVE air handler. Since it is made by Goodman, the largest HVAC manufacturer in America, you know you are getting a product that will install quickly and last well into the future.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
AHVE36CP0300

General Information
Type
Air Handler
Product Line
AHVE
Product Category
Air Handler
Refrigerant Type
R-32
Blower Motor Type
ECM Variable-Speed
Motor Type
ECM
Configuration
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Horizontal
Installation Location
Indoor
Electric Heat
Available
Installation Available
Yes
TXV Installed
Yes
UPC
663051735248
Performance
Capacity
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
3.0 Tons
Cooling BTU
36000
Maximum Air Flow
1260 CFM
Minimum Air Flow
800 CFM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
6.5 Amps
Recommended Breaker Size
15 Amps
Dimensions
Suction Connection Size
7/8 Inch
Liquid Connection Size
3/8 Inch
Drain Outlet Diameter
3/4 Inch
Cabinet Width
21 Inches
Product Height
53 7/16 Inches
Product Width
21 Inches
Product Depth
21 Inches
Product Weight
125 Pounds
Shipping Weight
140 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Limited Years
