Model: ALFH20231E
$63.00
Factory-Direct
Features
- All-Aluminum Coil
- Goodman's evaporator coils use a reliable all-aluminum design featuring fins and grooved tubes. This design maximizes surface area and optimizes heat transfer for efficient comfort.
- Energy-Efficient Circulation
- PSC blower motors are energy hogs. The ECM motor in the ASPT61D14 provides more efficient, more intelligent airflow for your home.
- Dehumidification
- Goodman's air handlers make it easy to stay cool. The ASPT61D14 is designed to remove moisture from the air, letting you feel cool at higher temperatures.
- SmartFrame™
- The ASPT features Goodman's SmartFrame™ sub-structure for enhanced accessibility. It provides tool-less access to the filter rack and includes a coil mounting track that improves installation speed for all four compatible orientations.
- Secure Cabinet
- This air handler enjoys reduced noise levels, less than 2% air leakage, and enhanced durability as a result of its insulated, embossed cabinet design.
- Condensate Management
- The ASPT's design includes molded diverters, foil-faced insulation, and screw-less construction that help prevent the formation of condensation. A thermoplastic drain pan is included to handle any condensate that does form.
- Extended Warranty
- Goodman offers a 10-year limited parts warranty when you register your product online within 60 days of installation. An unregistered product has the standard 5-year warranty. See warranty sheet under the "Manuals" tab for more information.
- Internal Thermostatic Expansion Valve
- The ASPT Series Air Handler has a factory-installed internal thermostatic expansion valve. This streamlines installation and maintains ideal refrigerant flow for your system.
The best air conditioner or heat pump in the world is all for naught if your home lacks proper airflow. That's where the Goodman ASPT air handler comes in. The ASPT is all about effective air distribution. It includes an all-aluminum evaporator coil and internal thermostatic expansion valve. These advanced components excel at ensuring that your home stays comfortable and your central system runs efficiently. The ECM fan motor is a huge step up from older models as it requires less electricity to operate and provides more consistent air circulation. The ASPT61D14 was designed and built with an emphasis on keeping the installation process short and the equipment's lifespan long to maximize the value for homeowners. If airflow issues are holding your central system back, invest in an ASPT air handler from Goodman.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
ASPT61D14
Overview
Product Category
Air Handler
UPC
663051559677
General Information
Type
Air Handler
Product Line
ASPT
Product Category
Air Handler
Refrigerant Type
R-410A
Blower Motor Type
Multi-Speed
Motor Type
EEM
Mount Type
Multi-Position
Installation Location
Indoor
Electric Heat
Available
Installation Available
Yes
TXV Installed
Yes
Performance
Capacity
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
5.0 Tons
Cooling BTU
60000
Maximum Air Flow
2340 CFM
Minimum Air Flow
1055 CFM
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
9 Amps
Recommended Breaker Size
15 Amps
Dimensions
Suction Connection Size
7/8 Inch
Liquid Connection Size
3/8 Inch
Cabinet Width
24 1/2 Inches
Product Height
58 Inches
Product Width
24 1/2 Inches
Product Depth
21 Inches
Product Weight
112 Pounds
Shipping Weight
167 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
Warranty Information
Warranty
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Limited Years
Reviews
(3)
Goodman ASPT61D14 Reviews & Ratings
Great Performance For Price.
By Keith B
Reno, Nevada
Purchased 06/26/2021 |
Review Posted 07/23/2021
Unit was specifically what we needed and worked well. Documentation isn't real clear for parts of the install, but unit is good quality construction and performed far better than expected. Have in 8000 SF aircraft hanger that's very well insulated and keeps it at 78 when 95 outside.
Keith B Recommends This
Was this review helpful?
Rating Breakdown
5/5
4/5
5/5
5/5
Pros:
Price, Exceeded Expectations, High Quality, Id Buy It Again
Cons:
Bad Instructions
Love Goodman and eComfort
By Paul S
NORTH ANDOVER, Massachusetts
Purchased 08/21/2018 |
Review Posted 09/21/2018
I was skeptical about Goodman. I’ve always had Carrier but I have to say this is equal quality and performance at a fraction of the cost. eComfort has also been a great company to work with. You can’t go wrong with Goodman. I would definitely recommend
Paul S Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Easy to configure unit.
By William G.
Boca Raton, Florida
Purchased 07/07/2018 |
Review Posted 08/01/2018
This unit works in vertical or horizontal positions. I removed the horizontal drain pan, as directed by the manual, to optimize vertical air flow. It states it is not required but I want better air flow. The A coil in my 5 ton unit is massive but slides out easily. This is a well constructed unit.
William G. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Durable, Exceeded Expectations, High Quality, I'd Buy It Again
How-To Articles
How Central Air Conditioning Systems Work
Can you imagine life without air conditioning? Oppressive heat waves that can m...
How to Pick the Perfect Evaporator Coil & Air Handler
Evaporator coils and the refrigerant that flows through them are the veins and ...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Goodman ASPT - 5 Ton - Air Handler - Multi-Position - ECM Motor
