Goodman AVPTC - 3 Ton - Air Handler - Multi-Position - Variable Speed Motor

Model:

AVPTC39C14

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Goodman AVPTC - 3 Ton - Air Handler - Multi-Position - Variable Speed Motor
Goodman AVPTC - 3 Ton - Air Handler - Multi-Position - Variable Speed Motor
Model: AVPTC39C14
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The best air conditioner or heat pump in the world is all for naught if your home lacks proper airflow. Luckily, Goodman's AVPTC air handler provides effective air distribution for homes of nearly all shapes and sizes. It includes an all-aluminum evaporator coil, variable speed fan motor, and internal thermostatic expansion valve. These cutting edge components improve the efficiency of your system and the consistency of your comfort. If you're looking for perfect air circulation, look no further than the AVPTC39C14 air handler. Since it is made by Goodman, the largest HVAC manufacturer in America, you know you're getting a product that will install quickly and last well into the future.
  • All-Aluminum Coil
  • Goodman's evaporator coils use a reliable all-aluminum design featuring fins and grooved tubes. This design maximizes surface area and optimizes heat transfer for efficient comfort.
  • Energy-Efficient Circulation
  • By scaling the airflow to the demands and challenges of your home, the advanced variable speed blower motor in the AVPTC provides ideal airflow through shifting conditions in nearly any applicationâ
  • Internal Thermostatic Expansion Valve
  • The AVPTC39C14 has a factory-installed internal thermostatic expansion valve. This streamlines installation and maintains ideal refrigerant flow for your system.
  • Dehumidification
  • Goodman's air handlers make it easy to stay cool. The AVPTC is designed to remove moisture from the air, letting you feel cool at higher temperatures.
  • SmartFrame™
  • This air handler features Goodman's SmartFrame™ sub-structure for enhanced accessibility. It provides tool-less access to the filter rack and includes a coil mounting track that improves installation speed for all four compatible orientations.
  • Secure Cabinet
  • This air handler enjoys reduced noise levels, less than 2% air leakage, and enhanced durability as a result of its insulated, embossed cabinet design.
  • Condensate Management
  • The AVPTC's design includes molded diverters, foil-faced insulation, and screw-less construction that help prevent the formation of condensation and keep your system running smoothly.
  • ComfortBridge Compatible
  • This air handler is compatible with Goodman's ComfortBridge communicating controls. A ComfortBridge control shortens the installation and maintenance processes by automatically detecting your equipment and providing diagnostics and troubleshooting.
  • Extended Warranty
  • Goodman offers a 10-year limited parts warranty when you register your product online within 60 days of installation. An unregistered product has the standard 5-year warranty. See warranty sheet under the "Manuals" tab for more information.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

AVPTC39C14
specs product image PID-80166
Overview
Product Category
Air Handler
UPC
663051564473
General Information
Type
Air Handler
Product Line
AVPTC
Product Category
Air Handler
Refrigerant Type
R-410A
Blower Motor Type
Variable-Speed
Motor Type
ECM
Mount Type
Multi-Position
Installation Location
Indoor
Electric Heat
Available
Installation Available
Yes
TXV Installed
Yes
Performance
Capacity Learn More
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
3.0 Tons
Cooling BTU
36000
Maximum Air Flow
1180 CFM
Minimum Air Flow
780 CFM
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
7 Amps
Recommended Breaker Size
15 Amps
Dimensions
Suction Connection Size
7/8 Inch
Liquid Connection Size
3/8 Inch
Cabinet Width
21 Inches
Product Height
49 Inches
Product Width
21 Inches
Product Depth
21 Inches
Product Weight
102 Pounds
Shipping Weight
118 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Limited Years
