Hotpoint - 9k BTU - Packaged Terminal Air Conditioner (PTAC) - 3.4 kW Electric Heat - 208-230 Volt - R-32

Model:

AH12E09D3B

Write A Review
$629.00
Was $880.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
synchrony card logo
$105 / Month
Suggested monthly payments with 6 month financing.
Hotpoint - 9k BTU - Packaged Terminal Air Conditioner (PTAC) - 3.4 kW Electric Heat - 208-230 Volt - R-32
Hotpoint - 9k BTU - Packaged Terminal Air Conditioner (PTAC) - 3.4 kW Electric Heat - 208-230 Volt - R-32
Model: AH12E09D3B
$629.00
Was $880.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Plug Type (NEMA 6-20P): This appliance uses NEMA 6-20P standard size power plug. It's designed for a 240V 20A household power supply. Please verify that your home's power supply is compatible with this appliance before purchase.
    Engineered for durability, Hotpoint PTACs are bult with durable materials to withstand the elements. The self-diagnostics feature helps you identify service needs, making service calls quick and easy. Hotpoint PTACs gives the guests control over their comfort with an easy-to-use control panel.
  • Three Speed Fan
  • Hotpoint PTACs come with three different fan speeds to choose from, giving every guest control over their own comfort.
  • Four Temperature Limiting Options
  • All Hotpoint PTACs offer four temperature options for comfort and peak efficiency.
  • Intuitive Display
  • The control panel of the Hotpoint PTACs allow guest to easily set their preferred settings, helping reduce maintenance calls.
  • Power Cord Included
  • Hotpoint PTACs are equipped with a LCDI cord for fast and easy installation.
  • Freeze and Frost Protection
  • Hotpoint PTACs operate in peak conditions with indoor frost and automatic freeze control.
  • Auto Power Recovery
  • Hotpoint PTACs automatically resume operation after a power failure, reducing maintenance calls.
  • Self-Diagnostics
  • Each Hotpoint PTAC comes with a nine-point diagnostic code system that makes it easy to solve service issues.
  • Product Note
    PTAC units require a wall sleeve and exterior grille for functionality. These can be found under the "Recommended Accessories" tab.
  • The state of California requires 10.9 EER when replacing your PTAC. In new construction applications, the state of California requires 14 EER.
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

AH12E09D3B
specs product image PID-145769
General Information
Type
PTAC
Product Line
AH12E
Product Category
PTAC Unit
Operating Mode Learn More
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Cooling + Electric Heat
Refrigerant Type
R-32
Electric Heat
Yes
DOE Regional Compliance Learn More
DOE Regional Compliance
In 2015, the US Department of Energy broke the country into three regions - North, Southeast, and Southwest - and set legal standards for energy efficiency within each region. Learn More
Nationwide
UPC
084691923855
Performance
Cooling BTU
9000
Cooling Capacity
9200 BTU
Electric Heat Capacity
3.4 kW
EER Learn More
EER
EER (Energy Efficiency Ratio) is a measurement of cooling efficiency under fixed conditions. It is useful for comparing units that will operate consistently under one set of conditions (e.g. server room). The higher the EER, the more efficient the system. Learn More
11.3
Cooling Power Input
810 Watts
Maximum Air Flow
434 CFM
Minimum Air Flow
340 CFM
Heating Power Input
3535 Watts
Minimum Operating Temperature
62 F
Maximum Operating Temperature
86 F
Electrical Data
Plug Type
NEMA 6-20P
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Recommended Breaker Size
20 Amps
Dimensions
Product Height
16 Inches
Product Width
42 Inches
Product Depth
21 Inches
Product Weight
105 Pounds
Shipping Weight
130 Pounds
Certifications
AHRI Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
