Hydrolevel Safgard 650 Commercial Hot Water Boiler Low Water Cut-Off, 120 VAC, EL1214-SV 3/4" NPT Probe

Name: Hydrolevel Safgard 650 Commercial Hot Water Boiler Low Water Cut-Off, 120 VAC, EL1214-SV 3/4" NPT Probe
Brand: Hydrolevel
SKU: 36211
Price: 233.00 USD
Availability: InStock
Rating: 5.00 (1 reviews)

Model:

650SV

Write A Review

$233.00

Free Shipping

Factory-Direct

Ships in 4-7 Business Days

$39 / Month

Suggested monthly payments with 6 month financing.

Click for important monthly payment and offer information.

Hydrolevel Safgard 650 Commercial Hot Water Boiler Low Water Cut-Off, 120 VAC, EL1214-SV 3/4" NPT Probe

Model: 650SV

$233.00

Features

Specifications

Reviews

Product Q&A

How-To Articles

Manuals

Features

The Safgard Commercial Boiler Low Water Cut-Offs are used as the primary low water cut-off on residential and commercial water boilers. Hydrolevel controls utilize a non-moving, heavy duty, electronic probe to sense liquid levels. The probe can be installed in an equalizing line or directly into a boiler or water tank in accordance with manufacturers' instructions and local and State codes. When water is in contact with the probe, it completes a circuit between the stainless steel probe tip and the tank or boiler surface in which the probe is installed. When the water level drops below the probe, the circuit opens. Hydrolevel low water cut-offs for hydronic heating systems use the water signal to allow the burner to operate. If the water level drops below the probe, the circuit opens and the cut-off shuts down the burner. Automatically restarts burner on return of normal water level.

Heavy-duty electro-mechanical design
for long life.
Automatically shuts off burner in a low water condition
to prevent boiler damage.
Low maintenance
No moving parts to wear stick or hand up, as in float devices.
Rugged construction
Designed for the heating professional.
More Probe Plate Space
Large probe tip puts more conductive surface area in the water, leading to more dependable operation and less chance of nuisance boiler shutdowns.
Automatic Reset
Shuts down the burner when water drops below the probe. Automatically recompletes the burner circuit upon return of a safe water level.
Test Button
Tests control operation without lowering the water level. Depressing the test button shuts down the burner after two second delay and lights low water indicating LED. Depressing the test button a full 30 seconds will send control into manual reset.
