King Electric - 15/20000 BTU - Large Hydronic Wall Heater with Aqua Stat and Fan Switch

Model:

HL1412 15/20-AS/FS-GW

Write A Review
$1,748.89
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 4-6 Weeks
synchrony card logo
$292 / Month
Suggested monthly payments with 6 month financing.
King Electric - 15/20000 BTU - Large Hydronic Wall Heater with Aqua Stat and Fan Switch
King Electric - 15/20000 BTU - Large Hydronic Wall Heater with Aqua Stat and Fan Switch
Model: HL1412 15/20-AS/FS-GW
$1,748.89
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The King Electric HL Series large hydronic heater is intended to fit neatly between standard wall studs. With the ability to use the energy from a building's hot water source the HL Series large hydronic heater offers efficient, whisper quiet operation and the ability to reduce utility bills with individual thermostat room control. Easily heat only the areas in use and conserve energy by installing hydronic systems in every room.
  • King Electric HL Series Features
  • Flow-Through Design
  • Tangential Blowers For Whisper Quiet Operation
  • Compatible With Typical Hot Potable Water Sources
  • Fast Coil Heating For Heat Transfer

Specifications

HL1412 15/20-AS/FS-GW
specs product image PID-115024
Overview
Product Category
Unit Heater
UPC
093319212288
General Information
Type
Hydronic Heaters
Product Line
HL
Product Category
Unit Heater
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Electric
Blower Motor Type
Permanently Lubricated Motor
Mount Type
Wall
Color
White
Performance
Heating BTU
20000
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
26000 BTU
Maximum Air Flow
375 CFM
Electrical Data
Voltage
120 Volts
Minimum Circuit Ampacity
0.42 Amps
Recommended Breaker Size
15 Amps
Current Draw
0.42 Amps
Dimensions
Product Height
26 1/4 Inches
Product Width
15 1/2 Inches
Product Depth
4 3/4 Inches
Product Weight
25 Pounds
Shipping Weight
28 Pounds
Certifications
Country of Origin
US
ETL Listed
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Heating Element Warranty
2 Years
