Features
- Kohler™ 12RES Home Standby Generator
- Requires Kohler RDT Automatic Transfer Switch (Sold Separately)
- Kohler™ Command PRO® OHV Engine
- Meets emission regulations for U.S. EPA & California
- Powerful and reliable engine with hydraulic valve lifters
- Simple field conversion between natural gas and LP
- Premium Warranty
- Covered by a 5-Year / 2,000-Hour Limited Warranty
- PowerBoost™ Technology
- Greater motor-starting ability for large electrical loads
- Provides enough power to start a 4-Ton (48,000 BTU) central AC
- Cleaner Power for Sensitive Electronics
- Protects sophisticated electronics with low distortion (THD)
- Faster Response
- Kohler™ generators restore power in as little as 10 seconds
- Quiet Operation
- Maintains neighborhood solitude 65 dB(A) at 7 m (23 ft)
- ADC-RES Advanced Digital Control
- Digital voltage regulation & engine speed governing
- LED display shows system status and setup information
- Easy Installation
- Polymer base eliminates the need for a concrete pad
- Load connection terminal block allows easy field wiring
- Galvanneal® Steel Enclosure
- Automotive-grade paint for superior corrosion-protection
- Rodent-proof construction prevents unwanted pests
- **Compatible For Off-Grid Applications***
- 18-Month / 1000-Hour Off-Grid Limited Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
12RES-QS11
General Information
Product Category
Generator - Standby
Overview
Product Category
Generator - Standby
Weight
400 Pounds
CARB Compliant
Yes
Made in USA
Yes
Consumer Warranty
5 Years
Commercial Warranty
5 Years
Product Style
Standby Generator
Product Length
44.2 Inches
Product Width
28.6 Inches
Product Height
31.6 Inches
UPC
650531349521
Additional Model Numbers
12RES, 12RES-QS11
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
12000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
10400 Watts
LP Power Capacity
12000 Watts
NG Fuel Consumption @ 50% Load
124 ft³/hr
NG Fuel Consumption @ 100% Load
193 ft³/hr
LP Fuel Consumption @ 50% Load
1.8 gallons/hr
LP Fuel Consumption @ 100% Load
2.3 gallons/hr
Rated Amps
50 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
65
Transfer Switch
Automatic (Not Included)
Battery
Not Included (525 CCA)
Enclosure
Steel
A/C Ton Rating
4-Tons
Mounting Pad
Composite (Included)
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Wi-Fi Remote Monitoring
Sold Separately
Engine
Engine Brand
Kohler
Starting System
12v Auto Start
CC
725 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
