Kohler RXT Series 100-Amp Indoor Automatic Transfer Switch w/ 12-Circuit Load Center
Model:
GM85273-SA6
+
Share This Product
Recommended Accessories
![eComfort expert image](http://www.powerequipmentdirect.com/images/experts/expert-avatar-15-18.png?v=1)
Expert Recommended Accessories
Selected by Ken, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
- Kohler Model RXT 100-Amp Indoor Automatic Transfer Switch
- Only compatible with Kohler generators with RDC2/DC2 controllers
- 12-Circuit Load Center (Breakers Not Included)
- Provides the ability to back up select circuits
- NEMA 1R Indoor Steel Enclosure
- Designed for indoor installation
- Standard Features
- Allows utility voltage display on RDC2/DC2 controller
- Interface board for connection to the RDC2/DC2 controller
- Double throw inherently interlocked design
- Added Safety
- Contractor manually operable for maintenance purposes
- Rated at 100-Amps @ 240-Volts
- 5-Year Limited Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
GM85273-SA6
![specs product image PID-112612](/products-image/150/gm85273-sa6_112612_2000_5c9f84aad2742be5c8720127509931b0.jpg)
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
26 Pounds
Consumer Warranty
5 Years
Product Depth
6 Inches
Product Width
13 Inches
Product Height
24 Inches
UPC
650531462657
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Amps
100 Amps
Enclosure
NEMA 1R
Number of Circuit Breakers
12
Transfer Switch Style
Standard Installation
ATS Load Prioritizing
Not Included
ATS Load Shedding
Not Included
ATS Poles
2 Poles
ATS Service Disconnect
No
Max Utility Input
100 Amps
Max Generator Input
100 Amps
UL Listed
Yes
