Kohler RXT Series 200-Amp Outdoor Automatic Transfer Switch (Service Disconnect)

Model:

RXT-JFNC-200ASEQS5

Write A Review
$900.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Backordered
Estimated Availability December 18, 2024
Shipping to60601
synchrony card logo
$150 / Month
Suggested monthly payments with 6 month financing.
Kohler RXT Series 200-Amp Outdoor Automatic Transfer Switch (Service Disconnect)
Kohler RXT Series 200-Amp Outdoor Automatic Transfer Switch (Service Disconnect)
Model: RXT-JFNC-200ASEQS5
$900.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

  • Kohler RXT Series 200-Amp Automatic Transfer Switch
  • Only compatible with Kohler generators with RDC2/DC2 controllers
  • Service Entrance Rated
  • Includes disconnect circuit breakers on both sources
  • Corrosion-Resistant NEMA 3R Aluminum Enclosure
  • Approved for indoor or outdoor installations
  • Switch can be padlocked for additional safety
  • Standard Features
  • Allows utility voltage display on RDC2/DC2 controller
  • Interface board for connection to the RDC2/DC2 controller
  • Double throw inherently interlocked design
  • Combined Interface / Load Management Board
  • Built-In Load Shed - Manage (2) HVAC loads
  • Manage up to (4) Non-Essential loads***
  • Added Safety
  • Contractor manually operable for maintenance purposes
  • Rated at 200-Amps @ 240-Volts
  • ***Requires PRM (Sold Separately)
  • 5-Year Limited Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

RXT-JFNC-200ASEQS5
specs product image PID-8060
General Information
Product Category
Generator Transfer Switches
Overview
Product Category
Generator Transfer Switches
Weight
26 Pounds
Consumer Warranty
5 Years
Product Depth
6.9 Inches
Product Width
16.4 Inches
Product Height
28.9 Inches
UPC
650531125132
Additional Model Numbers

RXT -JFNC-0200ASE, RXT-JFNC-200ASEQS5

Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Amps
200 Amps
Enclosure
NEMA 3R
Transfer Switch Style
Service Disconnect
ATS Load Shedding
Built-In
ATS Poles
2 Poles
ATS Service Disconnect
Yes
Max Utility Input
200 Amps
Max Generator Input
200 Amps
Maximum Wattage
48000 Watts
UL Listed
Yes

Reviews

(18)
Kohler RXT-JFNC-200ASEQS5 Reviews & Ratings

Product Q&A

(2)
Expert avatar photo
Product Questions Answered by Ken, the eComfort Product Expert
Does this automatic transfer switch include load shedding capability?
Justin
from Texas
December 17, 2020
I am thinking of buying a 20,000 watt Kohler standby. I have two 200-amp service panels. Can I get two Kohler automatic transfer switches that will feed those two service panels from the one 20,000 watt generator?
Ken Fetting
from Ohio
December 06, 2013
