Features
- Air Flow Options
- This unit gives you two options for automating air flow. In swing mode, the unit will rotate through all four air flow directions. Chaos Wind mode cycles both air flow direction and fan speed to provide a natural circulation pattern.
- Quiet Design
- The LMAN097HVP can operate at volumes as low as 31 dB thanks to its advanced fan motor. The brushless direct current motor reduces electrical and mechanical sound while providing powerful air movement.
- Self-Cleaning Coil
- The LMAN097HVP features a self-cleaning heat exchanger coil that automatically removes dirt and moisture. This helps to prevent unpleasant odors and to combat the formation of mold.
- Jet Temperature Control
- Quickly get your zone comfortable with the Jet Heat and Jet Cool modes. With the press of a button, your system will temporarily adjust the set point and fan speed to provide rapid heating or cooling.
- Automated Operation
- Auto operation mode continually compares your zone's current and desired temperatures and uses that data to intelligently adjust the unit's fan speed and refrigerant flow to provide optimal comfort.
- Sleep Mode
- With the sleep mode and timer functions, you can set this indoor unit to save energy at night. Sleep mode will incrementally adjust temperature for an hour before the timer function automatically deactivates the unit.
- Dehumidify
- LG's multi-zone indoor units include a dehumidifying operation mode. In this mode, the unit's internal sensors monitor temperature and modify the set point and fan speed to remove moisture from the air.
- Improved Air Quality
- The LMAN097HVP features an anti-fungal filter to keep your air clean. This filter captures contaminants like dust and bacteria, and it is washable to ensure long term air quality.
- Hot Start
- When the hot start function is enabled, the LMAN097HVP's fan will not engage until the outdoor condenser has had the opportunity to warm the indoor coil. This prevents the unit from blowing cold air during heating operations.
- Product Compatible With
- LG LMU183HV Mini Split Outdoor Condensers
- LG LMU243HV Mini Split Outdoor Condensers
- LG LMU303HV Mini Split Outdoor Condensers
- LG LMU363HV Mini Split Outdoor Condensers
- LG LMU541HV Mini Split Outdoor Condensers
- Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
- Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing.
- Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
LG's devotion to providing efficient ductless solutions can be seen across the Multi F line of indoor units. This unit allows you to hide your heating and cooling equipment in plain sight. The LMAN097HVP is part of LG's Art Cool Gallery line, which combines a triple air outlet mini split indoor unit and a fashionable frame for a 20" x 20" piece of art. Beauty isn't the only advantage of an Art Cool Gallery though; these units are also packed with useful features and advanced operating modes that make it easy to stay comfortable.
Product Note
This product requires a compatible LG mini split outdoor condenser and the following accessories for indoor unit installation:
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
LMAN097HVP
Overview
Product Category
Mini Split System Components
UPC
048231372480
General Information
Type
Wall Mounted
Product Line
Multi F
Product Sub-line
Art Cool Gallery
Product Category
Mini Split System Components
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Remote Control
Wireless
Indoor Unit Size(s)
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
9
Installation Location
Indoor
Performance
Cooling BTU
9000
Cooling Capacity
9000 BTU
Maximum Air Flow
272 CFM
Minimum Air Flow
155 CFM
Minimum Sound Level
31 dB
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
39 dB
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
3/8 Inch
Liquid Connection Size
1/4 Inch
Drain Outlet Diameter
5/8 Inch
Product Height
23 5/8 Inches
Product Width
23 5/8 Inches
Product Depth
5 19/24 Inches
Product Weight
32 Pounds
Shipping Weight
37 Pounds
Certifications
ETL Listed
Yes
UL Listed
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Reviews
(8)
LG LMAN097HVP Reviews & Ratings
Customer Photos and Videos
Satisfied Customer
By Kenneth N
New York
Purchased 07/14/2023 |
Review Posted 09/04/2023
It took me a bit to hook this system up, due to the fact I ran into a bees nest!!
But afterwards it was all pretty easy, customer loves the art cool and it cranks.
The only other thing I'd say is u need info about operating remote and changing from Celsius to Fahrenheit. Had to go on line to find info
But afterwards it was all pretty easy, customer loves the art cool and it cranks.
The only other thing I'd say is u need info about operating remote and changing from Celsius to Fahrenheit. Had to go on line to find info
Kenneth N Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
Bad Instructions
Great product!
By Duke C
Lynwood, California
Purchased 08/02/2021 |
Review Posted 09/13/2021
Great product!
Duke C Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
High Quality, Id Buy It Again, Durable, Features
Customers love these units..
By Carlos B.
Plainville, Massachusetts
Purchased 02/26/2020 |
Review Posted 04/05/2020
The appearance knocks it out of the park. Great alternative to the conventional ductless split heads.
Carlos B. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Id Buy It Again, Quiet, Easy To Use, High Quality
LG Cool Art is an Excellent Product
By Laurence L.
Ocean Springs, Mississippi
Purchased 09/24/2019 |
Review Posted 10/16/2019
Easy install, quiet and very satisfied with quality... factory flares had to be re-done on a couple of the line sets.
Laurence L. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Features, Quiet, High Quality, I'd Buy It Again
Great Alternative
By Terry F.
Laguna Beach, California
Purchased 06/21/2019 |
Review Posted 08/06/2019
This is an affordable alternative to adding ducts to support a central heat and air system. I like the art gallery model, because it gives you the option of adding your own picture or print to the frame. I have 4 units in two different homes! Highly recommend this product.
Terry F. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Easy to use
By Katie M.
Washington
Purchased 08/24/2018 |
Review Posted 10/30/2018
We are really enjoying having this unit. It does a great job of keeping our small space warm or cool. When the temperature drops to the low 30's it seems to struggle to regulate and makes lots of noise in the process. Other then that it is a fairly quite machine.
Katie M. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
4/5
5/5
Why did I wait so long?
By Mike Y.
Wichita Falls, Texas
Purchased 09/15/2018 |
Review Posted 10/30/2018
Took to long to make this purchase. Quite, efficient. Would highly recommend to anyone that wants a quality unit.
Mike Y. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Awesome product so far they are working great
By Mark K
West Mifflin, Pennsylvania
Purchased 06/12/2018 |
Review Posted 07/04/2018
I purchased 2 of the 9k models for my 2nd floor and they have proven to cool both areas well. These models have some cool features built in that make them that much more versatile besides heating, cooling, dehumidifier they also have a self cleaning feature and some cool fan speed options.Along with the stylish design that gives you another option then the standard bar design.
As of now I have had these 9k units installed for a week with good performance and am happy to say they are extremely quiet. I hope in time these units reflect this review the same.
As of now I have had these 9k units installed for a week with good performance and am happy to say they are extremely quiet. I hope in time these units reflect this review the same.
Mark K Recommends This
Was this review helpful?
Rating Breakdown
5/5
4/5
4/5
3/5
Pros:
Easy To Use, Quiet, I'd Buy It Again
Cons:
Expensive
How-To Articles
eComfort Boosts Comfort and Energy Savings at Historic Home
Owning a historic home can be very rewarding. But those rewards come with respo...
How to Pick the Perfect Mini Split Suspended Indoor Unit
A ceiling-suspended mini split is the perfect ductless solution for large open ...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
LG Art Cool Gallery 9k BTU Wall Mounted Unit - For Multi-Zone
