Features
- Built in Wi-Fi
- The LSN180HSV5 has built in Wi-Fi, enabling the control of your LG air conditioner with smart enabled devices. Simply download the SmartThinQ® app on your smart device to get started.
- Air Flow Options
- This unit gives you two options for automating air flow. In swing mode, the unit will rotate through all four air flow directions to ensure consistent comfort in every corner of your room.
- Quiet Design
- The LSN180HSV5 can operate at volumes as low as 28 dB thanks to a combination of cutting edge components. LG utilizes a cross flow fan design that reduces noise levels by limiting the surface pressure of air flow.
- Self-Cleaning Coil
- The LSN180HSV5 features a self-cleaning heat exchanger coil that automatically removes dirt and moisture. This helps to prevent unpleasant odors and to combat the formation of mold.
- Jet Cool
- This LG unit feature a Jet Cool operation mode for rapid cooling. In this mode, the indoor unit observes a set point of 64 degrees Fahrenheit and the fan operates at maximum speed for 30 minutes to quickly cool your zone.
- Automated Operation
- Auto operation mode continually compares your zone's current and desired temperatures and uses that data to intelligently adjust the unit's fan speed and refrigerant flow to provide optimal comfort.
- Sleep Mode
- With the sleep mode and timer functions, you can set this indoor unit to save energy at night. Sleep mode will incrementally adjust temperature for an hour before the timer function automatically deactivates the unit.
- Dehumidify
- LG's multi-zone indoor units include a dehumidifying operation mode. In this mode, the unit's internal sensors monitor temperature and modify the set point and fan speed to remove moisture from the air.
- Improved Air Quality
- The LSN180HSV5 indoor unit uses a dual filtration system to keep your air clean. A washable anti-fungal filter is the first line of defense against dust and bacteria.
- Hot Start
- When the hot start function is enabled, the LSN180HSV5's fan will not engage until the outdoor condenser has had the opportunity to warm the indoor coil. This prevents the unit from blowing cold air during heating operations.
- Product Compatible With
- LG LMU24CHV, LMU36CHV, LMU540HV, and LSU180HSV5 Mini Split Outdoor Condensers
- Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units. Additionally, this unit requires 3/8 x 5/8 inch line sets in single zone applications and 1/4 x 1/2 inch line sets in multi zone applications. The unit includes all adapters required for each application.
- Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing.
- Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
LG's devotion to providing efficient ductless solutions can be seen across the Multi F line of indoor units. Their Standard line of wall mounted mini split units are the perfect blend of versatility and capability for nearly any application. Quiet operations and a clean design make the LSN180HSV5 a smart addition for all types of spaces from bedrooms to living rooms to garages. With a variety of operating modes and helpful functions, this well-rounded mini split indoor unit is an easy choice for any system. This product requires a compatible outdoor condenser for functionality.
Product Note
This product requires a compatible LG mini split outdoor condenser and the following accessories for indoor unit installation:
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
LSN180HSV5
Overview
Product Category
Mini Split System Components
UPC
048231385787
General Information
Type
Wall Mounted
Product Line
Multi F
Product Category
Mini Split System Components
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Remote Control
Wireless
Indoor Unit Size(s)
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
18
Installation Location
Indoor
Performance
Cooling BTU
18000
Cooling Capacity
18000 BTU
Maximum Air Flow
558 CFM
Minimum Air Flow
353 CFM
Minimum Sound Level
29 dB
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
45 dB
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Maximum Line Length
114.8 Feet
Gas Connection Size
5/8 Inch
Liquid Connection Size
3/8 Inch
Product Height
13 7/12 Inches
Product Width
40 9/16 Inches
Product Depth
9 13/16 Inches
Product Weight
31 Pounds
Shipping Weight
36 Pounds
Certifications
UL Listed
Yes
ETL Listed
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Reviews
(38)
LG LSN180HSV5 Reviews & Ratings
Customer Photos and Videos
Customer Rating
4.89
(38 Ratings)
98% recommend this product
5
(34)
(34)4(4)
(4)3(0)
(0)2(0)
(0)1(0)
(0)
Great Choice
By David B
Denver, North Carolina
Purchased 11/09/2020 |
Review Posted 12/01/2020
Installed system in an 800 sq ft garage with two non-insulated external walls. System works great. It easily maintains temperature at 70 degrees and the jet cool or heat gets the temperature there fast.
David B Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Easy To Use, High Quality, Features
Cons:
Bad Instructions
18000 Head
By Gary O
Palm Coast, Florida
Purchased 06/26/2020 |
Review Posted 07/29/2020
I miss ordered the head that I needed and hooked it up, it would not cool the room so I got in touch with eComfort and ordered the right one. They helped me out as much as they could since they couldn't take back the head that had been installed. The new one of the right size works GREAT! Thanks eComfort
Gary O Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Easy To Use, High Quality, Id Buy It Again
Cools as expected.
By Daniel K.
Silver Creek, New York
Purchased 06/08/2020 |
Review Posted 07/01/2020
Wall unit is noisier than expected. Something rattles. Fan is also loud at times. Louvres are great, horizontally and vertically. Instruction manual does not explain how set remote to automatically turn unit on/off to achieve desired temp. Unit constantly runs when powered on. Has only been installed a few weeks.
Daniel K. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
As advertized
By Edward C.
Westminster, Maryland
Purchased 07/29/2019 |
Review Posted 09/01/2019
Both units are quiet, relatively easy to install and performed as expected.
Edward C. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, I'd Buy It Again, Features, Easy To Use
So happy with my choice!
By Cris
New York
Purchased 07/31/2019 |
Review Posted 08/22/2019
I bought this unit to be installed in the lower level of a raised ranch house. The unit is so quiet and works great.
Cris Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
This is the best product ever!!
By Wanda N.
Tuckasegee, North Carolina
Purchased 07/29/2019 |
Review Posted 08/21/2019
This is the 4 th unit that we have bought for 4 different family’s homes. Everyone that sees ours in our home falls in love with it and wants one. Works great on ac and heating.
Wanda N. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
LG Excellence Dealer Review
By Rusty R.
Independence, Kansas
Purchased 07/30/2019 |
Review Posted 08/20/2019
My company is a LG Excellence dealer. We have dealt with other DFS manufacturers in the past. There is a reason we went all in with LG. You cannot find a better DFS or Duct ed system out there. If you engineer the system properly they fire up and work without any problems. If you use a LG Excellence dealer to do your install, you cant find a better warranty!
Rusty R. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Durable, Quiet, Price, High Quality
best product ever.
By Ron H.
Florence, Alabama
Purchased 06/29/2019 |
Review Posted 08/15/2019
great product, very happy.
Ron H. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Great Unit and Great Service!
By Eric H
Chandler, Arizona
Purchased 05/17/2019 |
Review Posted 06/19/2019
This is a great unit - As an additional unit just for the master it helped cool a master bedroom down 5 degrees in less than 2 hours in 110 degree weather!
Eric H Recommends This
Was this review helpful?
Rating Breakdown
3/5
5/5
5/5
5/5
Pros:
Quiet, Easy To Use, High Quality
Great experience
By Raymond F.
Livingston, Texas
Purchased 02/04/2019 |
Review Posted 02/27/2019
Excellent price/ value product
Raymond F. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Easy To Use, Price, I'd Buy It Again
How-To Articles
eComfort Boosts Comfort and Energy Savings at Historic Home
Owning a historic home can be very rewarding. But those rewards come with respo...
How to Pick the Perfect Mini Split Suspended Indoor Unit
A ceiling-suspended mini split is the perfect ductless solution for large open ...
eComfort How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
LG 18k BTU Wall Mounted Unit - For Multi or Single-Zone
