Mitsubishi SVZ-KP18NA
Mitsubishi SVZ-KP18NA
Hover to zoom
1 of 1

Mitsubishi - 18k BTU - M-Series Multi-Position Air Handler - For Multi or Single-Zone

Model:

SVZ-KP18NA

Write A Review
$1,988.25
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Only 4 In-Stock
Ships Tuesday, Mar 18th
Shipping to43085
synchrony card logo
$332 / Month
Suggested monthly payments with 6 month financing.
Mitsubishi - 18k BTU - M-Series Multi-Position Air Handler - For Multi or Single-Zone
Mitsubishi - 18k BTU - M-Series Multi-Position Air Handler - For Multi or Single-Zone
Model: SVZ-KP18NA
$1,988.25
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Optional Accessories 13
$45.00
In-Stock
Length (ft)
$160.00
In-Stock
$18.00
In-Stock
$194.25
Only 1 In-Stock
Model: PAC-USWHS002-WF-2
$199.00
In-Stock
$55.80
$192.60
$621.00
Only 2 In-Stock
$97.20
Only 5 In-Stock
$69.30
Only 1 In-Stock
$93.60
Only 5 In-Stock

Features

Mitsubishi - 18k BTU - M-Series Multi-Position Air Handler - For Multi or Single-Zone


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
    For over 50 years, Mitsubishi has remained at the forefront of the mini split industry thanks to their dedication to providing efficient, user-friendly comfort solutions. The SVZ-KP18NA is a heat pump air handler unit designed to bring high-efficiency temperature control to larger zones. This unit features a highly efficient, completely enclosed EC motor and a positive pressure cabinet with air leakage of less than 2.0%. Its unique blow through design allows for simple coil cleaning when the blower is removed. Pair the SVZ-KP18NA with a Mitsubishi outdoor condenser for efficient and effective home comfort for years to come.
  • Energy Efficient Circulation
  • The SVZ-KP air handler includes an ECM blower motor to provide more efficient and more intelligent airflow for your home.
  • Airtight
  • The SVZ-KP air handler features a positive pressure cabinet with less than 2.0% air leakage, allowing your comfort system to produce results at its full potential.
  • Simple Maintenance
  • With a removable blower, the air handler can be easily cleaned and maintained. The air handler also includes a washable filter to ensure the air in your home is as fresh as can be.
  • Flexible Venting
  • With the ability to be installed vertically or horizontally, the SVZ-KP air handler can be easily adapted to fit in any duct system.

Specifications

SVZ-KP18NA
specs product image PID-96623
Overview
Product Category
Mini Split System Components
General Information
Type
Ducted Vertical Air Handler
Product Line
M-Series
Product Category
Mini Split System Components
Operating Mode Learn More
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
Yes
Indoor Unit Size(s) Learn More
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
18
Installation Location
Indoor
Performance
Cooling BTU
18000
Cooling Capacity
18000 BTU
Maximum Air Flow
675 CFM
Minimum Air Flow
471 CFM
Minimum Sound Level
33 dB
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
41 dB
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
1/2 Inch
Liquid Connection Size
1/4 Inch
Product Height
39 13/16 Inches
Product Width
17 Inches
Product Depth
21 5/8 Inches
Product Weight
93 Pounds
Shipping Weight
106 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years

Reviews

(1)
Mitsubishi SVZ-KP18NA Reviews & Ratings
Verified Buyer
Verified Buyer
Easy And Fast To Install
By Leo K
Sammamish, Washington
Purchased 07/07/2020 |
Review Posted 06/30/2021
Everything was in great condition when it arrived. Installation instructions were clear. Quiet operations.
Leo K Recommends This
Was this review helpful?
Rating Breakdown
Features
5/5
icon-review-marker
Quality
5/5
icon-review-marker
Performance
5/5
icon-review-marker
Value
5/5
icon-review-marker
Pros:
Easy To Use, Quiet, Exceeded Expectations
