Panasonic Exterios 9k BTU Wall Mounted Unit - For Single-Zone

Model:

CS-XE9SKUA

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Panasonic Exterios 9k BTU Wall Mounted Unit - For Single-Zone
Panasonic Exterios 9k BTU Wall Mounted Unit - For Single-Zone
Model: CS-XE9SKUA
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Panasonic is a leading manufacturer of high quality electronic goods, and their air conditioners are no exception. Panasonic has over 53 years of air conditioning experience, allowing any consumer to purchase a Panasonic product knowing that the addition to their home or office will be efficient, reliable and easy to use. The CS-XE9SKUA Mini Split Indoor Unit is a perfect example of Panasonic's engineering aptitude. Provide comforting air to all areas of the room with the air sweep feature. The louver moves up and down in the air outlet providing continuous comforting air.
    Product Features

    ECONAVI
    ECONAVI Intelligent Sensors detect unconscious waste of energy using the Human Activity Sensor and Sunlight Sensor. It is able to monitor human location, movements, absence and sunlight intensity.

    Air Sweep Control
    This function controls the louvers up and down to direct the air in a sweeping motion, providing comfort in all parts of the room.

    Quiet Operation
    With the all new turbo fan and increased air path, the CS-XE9SKUA has reached one of the industry's lowest levels of noise.

    Power Failure Automatic Restart
    Your preset programmed operation can be reactivated once power is restored after a power failure.

    Room Freeze Protection
    Prevent any potential plumbing problems from sub zero temperatures. The room freeze feature turns on the heat pump if the temperature falls below freezing temperatures.

    Self-Diagnosing
    The CS-XE9SKUA is equipped with a self-diagnosing function that makes it easier to diagnose malfunctions and ultimately save on service labor costs.

    Automatic Heating and Cooling Changeover
    After you set the temperature and functions you desire, just relax. If the room temperature gets higher or lower the unit will adjust accordingly.

    Hot Start
    The heat pump will warm up before blowing air to prevent any cold drafts.

    Product Includes
    • CS-XE9SKUA Mini Split Indoor Unit
    • CWA75C4567 Wireless Remote
    • Filter
    • Mounting Hardware
    Product Note
    • The Panasonic CS-XE9SKUA wall mounted indoor unit is not a complete mini split system. It contains only the CS-XE9SKUA indoor unit and requires a compatible Panasonic mini split outdoor Unit.
California residents see
Warning: This product can expose you to chemicals including Formaldehyde (gas) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

CS-XE9SKUA
specs product image PID-62990
General Information
Type
Wall Mounted
Product Line
Exterios
Operating Mode Learn More
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Multi-Zone Compatible
No
Refrigerant Type
R-410A
Remote Control
Wireless
Indoor Unit Size(s) Learn More
Indoor Unit Size(s)
Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.
9
Installation Location
Indoor
Performance
Cooling BTU
9000
Cooling Capacity
9000 BTU
Moisture Removal
1.3 Pints/Hour
Maximum Air Flow
470 CFM
Minimum Sound Level
26 dB
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
42 dB
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
3/8 Inch
Liquid Connection Size
1/4 Inch
Product Height
11 5/8 Inches
Product Width
34 13/48 Inches
Product Depth
10 1/16 Inches
Product Weight
24 Pounds
Certifications
Energy Star Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
