Features
- Compact Design
- Pensotti DD panel radiators use almost 1/4th of the space taken by traditional radiators.
- Quiet Operation
- With virtually silent operation, Pensotti panel radiators eliminate distracting noises commonly associated with other types of heating systems.
- Superior Heating
- Unlike traditional radiators that only give off convective heat, Pensotti panel radiators emit both radiant and convective heat to produce efficient warmth throughout your home.
- Simplicity and Durability
- Pensotti DD panel radiators are simply designed to fit in with your home's décor. These radiators are built to last and reduce the areas where household dust might collect.
- Product Includes
- (1) Thermostatic Insert
- (1) Air Vent
- (1) Wall Mounting Bracket Set
- (2) Reducers
- (2) 1/2" Pex Fittings
- (2) 1/2" Copper Fittings
- (2) White Escutcheons
- (2) White Pipe Covers
The Pensotti DD16.44DBL panel radiator provides the perfect combination of comfortable radiant heat with an elegant design. It is extremely versatile and can be used as the primary source of heating, a supplement to a radiant floor system, or as an addition with traditional heating sources. Unlike conventional baseboard radiators, Pensotti panel radiators emit both radiant and convective heat to achieve unsurpassed comfort and efficiency. Their durability and ease of service and install make them among the most unique panel radiators.
Product Note
A factory installed adjustable flow setter and 1/2\" x 3/4\" BSP adapter is included.
California residents see
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov
Specifications
HD16-44D
Overview
Product Category
Radiators
Additional Model Numbers
DD16.44DBL, HD16-44D
General Information
Type
Panel
Product Line
DD
Product Category
Radiators
Medium
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Connection Type
BSP
Material
Steel
Performance
Heating BTU
7000
Heating Capacity
6648 BTU
Maximum Operating Temperature
250 F
Maximum Operating Pressure
145 PSI
Dimensions
Supply Connection
1/2 Inch
Return Connection
1/2 Inch
Product Height
16 Inches
Product Width
44 Inches
Product Depth
4 1/8 Inches
Product Weight
57 Pounds
Warranty Information
Warranty
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
10 Years
