Revolv DGAH Compact - 56,000 BTU - Gas Furnace - Manufactured Home - NG - 80% AFUE - Single-Stage - Downflow - Multi-Speed

Model:

DGAH056BBSB

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Revolv DGAH Compact - 56,000 BTU - Gas Furnace - Manufactured Home - NG - 80% AFUE - Single-Stage - Downflow - Multi-Speed
Revolv DGAH Compact - 56,000 BTU - Gas Furnace - Manufactured Home - NG - 80% AFUE - Single-Stage - Downflow - Multi-Speed
Model: DGAH056BBSB
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Revolv, a division of Coleman, is dedicated to bringing efficient comfort to the manufactured and mobile home market. The DGAH056 is a downflow furnace capable of providing 47,000 BTU of heating at an 80% efficiency. Designed for easy installation in a variety of applications, it enjoys a 0" required clearance to combustibles at the rear and sides and only 2" are required at the top of the unit. If you're struggling to effectively and safely heat your manufactured home, the DGAH056 is a solution that you can believe in.

    Product Features

    Safety First
    Safety is always a concern in heating, but especially so in the tighter quarters of manufactured homes. The DGAH Compact series employs a fail-safe auto-ignition system with two separate limit controls for unparalleled peace of mind.

    Attractive and Durable
    Revolv employs a scratch-resistant white finish on the contoured upper and lower panels of their DGAH Compact furnace. This gives it a clean, neutral appearance that endures through wear and tear.

    Compact
    The DGAH Compact takes Revolv's classic DGAA Conquest design and reduces the vertical footprint down to five feet. By removing the Conquest's coil cabinet, Revolv has created a furnace that is more compact, more affordable, and perfect for manufactured homes in cold climates or those with existing cooling systems.

    Gas Conversion Kit
    All DGAH Compact furnaces are field convertible to liquid propane. A conversion plate and orifice are included with the gas valve, so that conversion can be handled during installation without requiring any additional parts.

    Internal Filtration
    The DGAH Compact doesn't just keep your home comfortable, it also keeps you air clean. Two air filters that capture dust, lint, and other contaminants are installed on the top door of the furnace where they are easy to check and replace.

    Product Includes
    • (1) Revolv DGAH056BBSB Gas-Fired Furnace
    • (1) Liquid Propane Conversion Kit
    • (2) Filters
    Product Note

    A 4000 Series roof jack is required to install this product. These roof jacks can be ordered from the accessories tab above.

California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

DGAH056BBSB
specs product image PID-27066
General Information
Type
Gas Furnace
Product Line
DGAH Compact
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Modulating/Staging Learn More
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Type Learn More
Blower Type
Blower type describes the motor that powers the fan in the unit. PSC multi-speed is the standard motor that operates with pre-set fan speed levels. ECM multi-speed are more efficient but still operate with pre-set fan speeds. Finally, ECM variable-speed motors are also energy efficient and automatically adjust to changing system conditions.
PSC Multi-Speed
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Downflow
Gas Conversion Kit
Included
UPC
883982707132
Performance
AFUE Learn More
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
80 %
Heating BTU
56000
High Fire Input
56000 BTU
High Fire Output
47000 BTU
Maximum Air Flow
1050 CFM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
12.4 Amps
Recommended Breaker Size
15 Amps
Dimensions
Product Height
60 Inches
Product Width
19 1/2 Inches
Product Depth
24 1/2 Inches
Product Weight
131 Pounds
Certifications
ETL Listed
Yes
UL Listed
Yes
CSA Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
AHRI Reference Number
2017045
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Heat Exchanger Warranty
10 Years
