Revolv MG2R - 45k BTU - Gas Furnace - Manufactured Home - 95% AFUE - Top Return - No Coil Cabinet
Model:
MG2R-045TA
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Optional Accessories
10
Features
- High Efficiency Heating
- Revolv MG2R furnaces are designed to save you money. Sporting a 95% AFUE efficiency rating, Revolv's high efficiency line will provide heat while keeping money in your pocket.
- ECM Motor
- The MG2R includes a high efficiency, multi-speed ECM blower motor, granting powerful CFM ratings at the fraction of the energy costs of traditional PSC motors.
- Category IV Venting
- The MG2R's efficient technology allows for vertical or horizontal direct venting using approved non-metallic components for application flexibility.
- Quick LP Conversion
- An easy-access gas valve regulator, manifold and included LP orifices make propane conversion a breeze.
Revolv is dedicated to bringing efficient comfort to the manufactured and mobile home market. The MG2R is a downflow gas furnace capable of providing 43,000 BTU of heating at 95% AFUE. Designed for easy installation in a variety of manufactured and modular homes, the MG2R features a small footprint and is HUD-compliant. The MG2R includes an efficient ECM blower motor, allowing for powerful airflow at the fraction of the energy cost as a traditional PSC motor. With durable construction and a dependable warranty, the Revolv MG2R is a reliable solution for your manufactured home heating needs.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
MG2R-045TA
Overview
Product Category
Furnace
UPC
663132389131
General Information
Type
Gas Furnace
Product Line
MG2R
Product Category
Furnace
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Motor Type
ECM Multi-Speed
Configuration
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Downflow
Gas Conversion Kit
Included
Performance
AFUE
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
95 %
Heating BTU
45000
High Fire Input
45000 BTU
High Fire Output
42750 BTU
Maximum Air Flow
1605 CFM
Ultra Low NOx Emissions
Ultra Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx. Learn More
No
Low NOx Emissions
Low NOx Emissions
NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Low NOx appliances emit less than 40 ng/J (nanogram per Joule) of NOx. Learn More
No
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Recommended Breaker Size
20 Amps
Dimensions
Flue Connection Size
2 or 3 Inches
Gas Connection Size
1/2 Inch
Cabinet Width
19 3/4 Inches
Product Height
56 Inches
Product Width
19 3/4 Inches
Product Depth
23 3/4 Inches
Shipping Weight
150 Pounds
Certifications
AHRI Certified
Yes
AHRI Reference Number
204600310
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
