Revolv RG1D56C3
Revolv RG1D56C3
Hover to zoom
1 Of 5

Revolv RG1 - 56k BTU - Gas Furnace - Manufactured Home - NG - 80% AFUE - Single-Stage - Downflow - Multi-Speed

Model:

RG1D56C3

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Revolv RG1 - 56k BTU - Gas Furnace - Manufactured Home - NG - 80% AFUE - Single-Stage - Downflow - Multi-Speed
Revolv RG1 - 56k BTU - Gas Furnace - Manufactured Home - NG - 80% AFUE - Single-Stage - Downflow - Multi-Speed
Model: RG1D56C3
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    Revolv is dedicated to bringing efficient comfort to the manufactured and mobile home market. The RG1D56N3 is a downflow furnace capable of providing 56,000 BTU of heating at an 80% efficiency. Designed for easy installation in a variey of manufactured and modular homes, it enjoys a 0" required clearance to combustibles at the rear and sides and only 6" are required at the top of the unit. If you're struggling to effectively and safely heat your manufactured home, the RG1D56N3 is a solution that you can believe in.
  • Sealed Combustion
  • Revolv RG1 furnaces vent directly to the outdoors and draw in fresh air for combustion through a separately purchased roof jack.
  • Multiple Cooling Choices
  • RG1 models can be paired with either air conditioners or heat pumps, up to 4 tons or 3.5 tons, respectfully.
  • Compact Design
  • All Revolv furnaces are designed specifically for manufactured and modular homes. This allows them to be installed in utility rooms or closets and streamlines installation.
  • High Quality, Low Maintenance
  • Features such as hot surface ignition, sealed bearings on the motors, reliable controllers, and a clean enamel finish means these units are made to last and provide uninterrupted comfort for years.
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

RG1D56C3
specs product image PID-78040
General Information
Type
Gas Furnace
Product Line
RG1
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type Learn More
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Direct Vent
Modulating/Staging Learn More
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Motor Type
PSC Multi-Speed
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Downflow
Maximum Altitude
2000 Feet
Gas Conversion Kit
Included
UPC
663132332809
Performance
AFUE Learn More
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
80 %
Heating BTU
56000
Heating Capacity
46000 BTU
Maximum Air Flow
1210 CFM
Minimum Air Flow
610 CFM
Electrical Data
Phase
1
Frequency
60 Hz
Recommended Breaker Size
15 Amps
Dimensions
Gas Connection Size
1/2 Inch
Product Height
76 Inches
Product Width
19 3/4 Inches
Product Depth
23 3/4 Inches
Product Weight
152 Pounds
Shipping Weight
152 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
AHRI Reference Number
8862024
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
2 Years
Heat Exchanger Warranty
10 Years
