Rinnai FC510 - 10k BTU - 99.9% AFUE - Vent-Free Gas Fan Convector

Model:

FC510N

Write A Review
$795.41
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships Wednesday, Nov 20th
Shipping to60601
synchrony card logo
$133 / Month
Suggested monthly payments with 6 month financing.
Rinnai FC510 - 10k BTU - 99.9% AFUE - Vent-Free Gas Fan Convector
Rinnai FC510 - 10k BTU - 99.9% AFUE - Vent-Free Gas Fan Convector
Model: FC510N
$795.41
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Features



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
    The Rinnai FC510N Vent-Free Fan Convector provides small space heating with efficiency and safety in mind. Using as little fuel as possible, the FC510N's convection fan evenly distributes warm air to hard to reach spaces. The FC510N eliminates the need for vents or ducts, places where the most heat is typically lost, making it one of the most efficient heating products on the market today. With integrated safety features including a cool-touch cabinet, power failure protection, and an oxygen depletion sensor, the FC510N provides home comfort with peace of mind.
  • Built for Efficiency
  • Rinnai's Vent-Free Fan Convectors boast an efficiency rating of 99.9%. The FC510N's vent-free system ensures distribution of heat that would otherwise be lost, while its temperature output control maintains efficiency when heat isn't needed.
  • Flexible Installation Options
  • Without the need for vents or ducts, the FC510N can be easily installed in almost any location in your home.
  • Protection for Your Family
  • The FC510N features a cool-touch cabinet and a tilt switch to disable the heater when it is knocked over - a major advantage if you have little ones running around your home. The FC510N also includes a control panel lock to prevent unintended operation.
  • Protection for Your Home
  • Rinnai's Vent-Free Fan Convectors include a variety of protection systems in the event of power failure, low oxygen levels, or overheating, granting you peace of mind whether you're home or away.
  • Product Note
    Vent-free heaters are prohibited to be sold or installed in the state of California.
California residents see
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

FC510N
specs product image PID-92630
Overview
Product Category
Electric Heater
UPC
766156008122
General Information
Type
Fan Convector
Product Category
Electric Heater
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Modulating/Staging Learn More
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Modulating
Connection Type
NPT
Mount Type
Floor
Installation Location
Indoor
Maximum Altitude
5200 Feet
Gas Conversion Kit
Not Available
Performance
AFUE Learn More
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
99.9 %
Maximum Input Capacity Learn More
Maximum Input Capacity
The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
10000 BTU
Minimum Input Capacity
5500 BTU
Maximum Air Flow
98 CFM
Minimum Air Flow
67 CFM
Minimum Sound Level
28 dB
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
38 dB
Electrical Data
Voltage
120 Volts
Power Consumption
19 Watts
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
1/2 Inch
Product Height
19 19/48 Inches
Product Width
19 5/24 Inches
Product Depth
9 29/48 Inches
Product Weight
22.1 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
3 Years
