Schwank AC-ME32-20-WH
Schwank AC-ME32-20-WH
Hover to zoom
1 Of 5

Schwank Swift5 Series 32" Electric Air Curtain - 208V - White

Model:

AC-ME32-20-WH

Write A Review
$1,015.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Estimated Availability 8-10 Weeks
  Learn More
Estimated Availability
Secure your place in line to receive this item once the manufacturer has provided us new inventory. Keep in mind orders are fulfilled in the order they are received. If you wish to no longer wait on the item, you are more than welcome to cancel the order. However, please keep in mind you will lose your place in line.
Shipping to60601
synchrony card logo
$170 / Month
Suggested monthly payments with 6 month financing.
Schwank Swift5 Series 32
Schwank Swift5 Series 32" Electric Air Curtain - 208V - White
Model: AC-ME32-20-WH
$1,015.00
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Features

    Schwank is a global family-owned enterprise, delivering comfort, energy savings and quality. With infrared heating, cooling and air movement solutions, Schwank has an extensive range of quality products for commercial and industrial spaces. Ideal for smaller openings like drive-thru windows, the Schwank Swift5 Series electric air curtain is easily mounted and delivers a sleek design that blends into your space. The Schwank Swift5 electric air curtain creates a temperature separating air barrier. This heated air barrier prevents cold air from coming in and keeps the warm from flowing out. Control entry of not only unconditioned air but also dust, fumes and insects. Install the Swift5 electric air curtain up to five feet high above kiosks, service hatches and more.
  • Heated Air Barrier
  • The Schwank Swift5 Electric Air Curtain provides a temperature separating air barrier to prevent cold air from pushing in.
  • Modern Design
  • With a corrosion proof housing made from hot zinc-plate and powder coated steel panels, the Schwank Swift5 Electric Air Curtain has a modern yet durable design.
  • Built-In Thermostat
  • The built-in thermostat and three speed settings allow you to adjust and set fan and heat settings.
  • Easy Installation
  • Mount the Schwank Swift5 on a horizontal wall or ceiling up to five feet high. The Swift5 is able to be angled on the mounting bracket for both wall and ceiling mounting.
  • Ideal for Use In
  • Small Entranceways and Drive-Thru Windows
  • Product Note
    Schwank Swift5 Air Curtains are supplied with a 4.3 foot cable without a plug.

Specifications

AC-ME32-20-WH
specs product image PID-149167
General Information
Type
Heated Air Curtain
Product Line
Swift5
Product Category
Air Curtain
Installation Location
Indoor
Electric Heat
Yes
Airfoil Finish
White
Performance
Electric Heat Capacity
2.5 kW
Maximum Air Flow
200 CFM
Maximum Sound Level Learn More
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
50 dB
Electrical Data
Voltage
208 Volts
Phase
1
Frequency
60 Hz
Dimensions
Product Diameter
6 29/48 Inches
Product Height
6 Inches
Product Width
32 Inches
Product Weight
17 Pounds
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
