Heat-flo - 60 Gallon - Multi-Energy Dual Coil Indirect Water Heater

Model:

HF-60-D

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Heat-flo - 60 Gallon - Multi-Energy Dual Coil Indirect Water Heater
Heat-flo - 60 Gallon - Multi-Energy Dual Coil Indirect Water Heater
Model: HF-60-D
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Multi-Energy Indirect Water Heaters are ideal for a variety of residential and commercial applications such as high domestic hot water demand and radiant loops. With coils that can be connected to solar collectors, you can achieve maximum efficiency with the Multi-Energy Indirect Water Heaters. Dual coils water heaters have two thermostats, allowing for each to be controlled independently and heat the whole tank.
  • Dual Coil
  • Featuring dual coils, the Heat-flo Multi-Energy Indirect Water Heater has a coil on the top and bottom of the tank.
  • Stainless Steel Construction
  • With the tank and coils made from stainless steel materials, the Heat-flo Multi-Energy Indirect Water Heater provides outstanding heat transfer. Stainless steel also provides a longer life to the tank and coils.
  • Coil Design
  • The Heat-flo Multi-Energy Indirect Water Heaters features large, dual coils with a smooth-wall design. With no finned tubing, the coils won't collect lime and sediment.
  • Simple Installation
  • All connections are on the top of the Heat-flo Multi-Energy Indirect Water Heater, making for a simple and easy installation.
  • Well Insulated
  • With over 2" of insulation, the Heat-flo Multi-Energy Indirect Water Heater provides less that 1° of heat loss. The thermoplastic jacket does not corrode and resists denting.

Specifications

HF-60-D
specs product image PID-104637
General Information
Type
Dual Coil Indirect Water Heater
Product Line
Heat-flo
Medium Learn More
Medium
Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
Hot Water
Fuel Type Learn More
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Indirect Fired
Storage Type
Tank
Coils Quantity
2
Connection Type
NPT
Dimensions
Storage Volume
60 Gallons
Cold Water Inlet
1 Inch
Hot Water Outlet
1 Inch
Supply Connection
1 Inch
Return Connection
1 Inch
Product Height
62 Inches
Product Width
23 1/2 Inches
Shipping Weight
135 Pounds
Warranty Information
Vessel Warranty
1 Year
