Williams Monterey - 35,000 BTU - Gas Fired Wall Furnace - NG - 66% AFUE - Single Sided
Model:
3509622A
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
12
$16.00
In-Stock
Model: 4915
$400.00
Factory-Direct
Model: P090543
$110.00
Factory-Direct
$110.00
Model: P322016
$35.00
In-Stock
$272.00
In-Stock
$110.00
Only 1 In-Stock
$192.00
In-Stock
$299.00
In-Stock
$110.00
Factory-Direct
Model: 9902
$110.00
Factory-Direct
Model: 9929
$290.00
In-Stock
Features
- Safe Pilot Ignition
- With matchless pilot ignition, the guess work is taken out of lighting the furnace. By sealing the pilot and ignitor away from dirt and debris, the electronic igniter lights the furnace safely and reliably.
- Power Free Operation
- A lot of things can go wrong during a power outage, but your furnace shutting off is not one of them. It will continue to work even when you lose power.
- Efficient Draft Hood Design
- The side-relief opening draft hood is designed to pull draft air from the sides of the furnace to limit heat loss through the chimney.
- Vent Limit Safety Switch
- The vent limit safety switch is equipped on all Monterey furnaces. This turns off the unit in case the chimney is blocked, protecting your family from carbon monoxide and fires.
- Optional Blower
- An optional blower offering manual or automatic operation is available. This improves circulation of the warm air and reduces temperature differences throughout the room.
The Williams Monterey Wall furnace is an ideal solution for you space heating needs. The patented side relief draft hood design reduces heat loss and ensures that you spend less and stay more comfortable. Whether recessed into the wall or surface mounted using the optional free standing kit, the soft-white powder coated finish provides a discrete durable finish that blends into any home's decor.
Product Note
A thermostat does not come included with this unit and is required. The Williams P322016 thermostat is compatible and can be found under the "Accessories" tab. Alternatively, any standard millivolt thermostat can be used. Product dimensions reflect measurement of furnace coming out from the wall.
California residents see
Warning: This product can expose you to chemicals including Epichlorohydrin which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
3509622A
Overview
Product Category
Furnace
UPC
093909298999
General Information
Type
Gas Wall Furnace
Product Line
Monterey
Product Category
Furnace
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Chimney Vent
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Gas Conversion Kit
Available
Performance
AFUE
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
66 %
Heating BTU
35000
High Fire Input
35000 BTU
High Fire Output
23700 BTU
Dimensions
Gas Connection Size
1/2 Inch
Product Height
65 3/4 Inches
Product Width
16 Inches
Product Depth
6 Inches
Shipping Weight
83 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Reviews
(10)
Williams 3509622A Reviews & Ratings
Customer Rating
4.80
(10 Ratings)
88% recommend this product
5
(8)
(8)4(2)
(2)3(0)
(0)2(0)
(0)1(0)
(0)
Easy Install
By Michael G
California
Purchased 12/09/2024 |
Review Posted 01/10/2025
This unit was purchased to replace a 40-year-old Williams with the same specs. The unit arrived with a couple of bent louvers which were not too hard to straighten. The new unit has a better control valve and updated burner. There is also an over-temperature safety in the flu, which the old unit did not have. The rooms that this covers are heating much faster. installation took less than 1 hour. If I had help it would have been even faster.
Michael G Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
5/5
5/5
Pros:
Easy To Use, I39d Buy It Again
Cons:
None
So Easy!
By Armando T
New Mexico
Purchased 12/09/2024 |
Review Posted 01/07/2025
I purchased a Williams Monterey - 35,000 BTU - Gas Fired Wall Furnace - NG - 66% AFUE - Single Sided to replace a similar Williams 35 BTU Wall Furnace that quit working after 30 Years! That's a long time. I thought that I was going to have a hard time replacing it. I was amazed how easy it was to complete this job. After removing the old unit and cleaning the space. The new model fit perfectly into the old space and I followed the directions to hook up the new model. turned on the gas, lit the Pilot light and turned the thermostat and the unit fired right up. It was so easy!
Armando T Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
None
Looks Good, Appears To Function As Should
By Peter C
Wisconsin
Purchased 09/11/2023 |
Review Posted 10/03/2023
I had to replace a wall unit, this one seems to have all the same features!
Peter C Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, Features
Best Price
By Alan M
San Diego, California
Purchased 01/07/2022 |
Review Posted 01/31/2022
good product, great price, fast shipping
Alan M Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Id Buy It Again, Price, Reliable
Great Product!!
By Edward G
Lancaster, Texas
Purchased 11/19/2020 |
Review Posted 02/13/2021
Works great, keeps the whole house warm...
Edward G Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Quiet, Exceeded Expectations, Id Buy It Again
Dandy
By Leslie M.
Wickenburg, Arizona
Purchased 03/18/2020 |
Review Posted 04/09/2020
Hardest part of install was putting on the cover. Took us about 2.5 hours to squeeze the unit into the opening, move the LP feed pipe a few inches from where it came up through the floor, and another 45 minutes trying to fit the face cover on - kept hanging up on screw heads along the sides. This replaced a 1962 Montgomery Ward model and so glad Williams makes the same exact size for the hole in the wall! Really puts out nice heat. Don’t know why HVAC company wanted $2K for the job. Moderate handyman skills saved us over $1300 for under 4 hours work.
Leslie M. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
a very good product !
By Lois S.
Big Rapids, Michigan
Purchased 12/11/2019 |
Review Posted 01/20/2020
It does a great job heating. We got good advice from people who service Williams products. Everything went good installing.
Lois S. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Good furnace for small space
By Amin A.
Ann Arbor, Michigan
Purchased 12/05/2019 |
Review Posted 12/30/2019
Good furnace for small space or mobile home. It doesn't have a fan so heat will rise quickly but there is a fan accessory you can buy or if you have a ceiling fan that will help to disperse heat. I bought a back register kit to heat the bedroom located behind the furnace, which I highly suggest for any similar room situation. Overall, a good buy for the price point.
Amin A. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
5/5
Pros:
Easy To Use, Price, Id Buy It Again
Cons:
No fan
So far So Good
By Caroline O.
North Hollywood, California
Purchased 11/21/2019 |
Review Posted 12/13/2019
Delivered in good condition and installed by my handyman in a couple hours. Puts off good heat.
Caroline O. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
4/5
GREAT FURNACE - BEST PRICE
By Lynne M.
Portal, Arizona
Purchased 11/12/2019 |
Review Posted 12/10/2019
Our second Williams wall furnace, the first one lasted 25 years! It arrived in a timely fashion, perfect condition, easy to install. This furnace was $400 cheaper than a well known home improvement store and the shipping was free. Will do business with ecomfort again and recommend them to all.
Lynne M. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Product Q&A
(1)
Product Questions
Answered by Ken, the eComfort Product Expert
If I choose the optional blower, will the heater itself still function during a power outage?
Alex
from California
December 06, 2021
