Williams Monterey PLUS - 50k BTU - Gas Top-Vent Wall Furnace - NG - 70% AFUE - Double-Sided
Model:
5009822
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
10
$16.00
In-Stock
Model: 4915
$400.00
Factory-Direct
Model: P090545
$110.00
Factory-Direct
$110.00
Model: P322016
$35.00
In-Stock
$192.00
In-Stock
$299.00
In-Stock
$110.00
Only 1 In-Stock
Model: 9902
$110.00
Factory-Direct
Model: 9929
$290.00
In-Stock
Features
- Safe Pilot Ignition
- With matchless pilot ignition, the guess work is taken out of lighting the furnace. By sealing the pilot and ignitor away from dirt and debris, the electronic igniter lights the furnace safely and reliably.
- Power Free Operation
- A lot of things can go wrong during a power outage, but your furnace shutting off is not one of them. It will continue to work even when you lose power.
- Efficient Draft Hood Design
- The side-relief opening draft hood is designed to pull draft air from the sides of the furnace to limit heat loss through the chimney.
- Vent Limit Safety Switch
- The vent limit safety switch is equipped on all Monterey PLUS furnaces. This turns off the unit in case the chimney is blocked, protecting your family from carbon monoxide and fires.
- Optional Blower
- An optional blower offering manual or automatic operation is available. This improves circulation of the warm air and reduces temperature differences throughout the room.
- Dual Room Heating
- Install the furnace in the wall between rooms and enjoy heat in both rooms with one unit.
The Williams Monterey PLUS+ Wall furnace is an ideal solution for you space heating needs. The patented side relief draft hood design reduces heat loss and ensures that you spend less and stay more comfortable. Whether recessed into the wall or surface mounted using the optional free standing kit, the soft-white powder coated finish provides a discrete durable finish that blends into any home's decor.
Product Note
A thermostat does not come included with this unit and is required. The Williams P322016 thermostat is compatible and can be found under the "Accessories" tab. Alternatively, any standard millivolt thermostat can be used.
California residents see
Warning: This product can expose you to chemicals including Epichlorohydrin which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
5009822
Overview
Product Category
Furnace
UPC
093909299033
General Information
Type
Gas Wall Furnace
Product Line
Monterey PLUS
Product Category
Furnace
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Chimney Vent
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Mount Type
Wall
Gas Conversion Kit
Available
Color
White
Performance
AFUE
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
70 %
Heating BTU
50000
High Fire Input
50000 BTU
High Fire Output
38000 BTU
Dimensions
Gas Connection Size
1/2 Inch
Product Height
65 3/4 Inches
Product Width
16 Inches
Product Depth
6 Inches
Product Weight
127 Pounds
Shipping Weight
137 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Heat Exchanger Warranty
Limited 10 Years
Reviews
(22)
Williams 5009822 Reviews & Ratings
Customer Rating
4.59
(22 Ratings)
89% recommend this product
5
(14)
(14)4(7)
(7)3(1)
(1)2(0)
(0)1(0)
(0)
Wall Furnace
By David L
Kansas
Review Posted 12/10/2022
This furnace is a good application for some of the older homes we service
David L Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
Pros:
Easy To Use
Heats But Loud
By Lara
Pacific Grove, California
Review Posted 10/29/2021
I bought this to replace an old Empire unit that had the same vent type and dimensions. It was packaged and shipped well- not a dent in the box. The furnace guy installed it in less than 2 hours without issue. The pilot light is quiet but it is really loud when it heats... sound like a wind tunnel. People have commented it is a calming sound albeit loud lol. It heats really well- quickly. It has my 1000 sq ft home in about 10 minutes and the cover does get hot. Since my heater is on a slightly higher level, I can see right inside the unit. The grill has larger square openings and I did prefer the look of the other cover. I would use that if I knew it would be safe, but with the heat output I think I'll stick with the cover it came with. Also, the power went out a few days after the installation and I WAS able to use it, which is very comforting in the area I live, as the power goes out a lot during the winter. The best features are the heat output and not needing electric.
Lara Does Not Recommend This
Was this review helpful?
Rating Breakdown
4/5
3/5
3/5
3/5
Pros:
Price, Features, Fast, Reliable
Cons:
loud, look of cover
Nice Fit.
By James P
Amherst, New York
Purchased 01/05/2021 |
Review Posted 01/27/2021
Finally can stop fighting the 50 year old unit this replaced. Designed to fit. Went in well, toasty happy tenant.
James P Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Price, High Quality, Id Buy It Again
Cons:
None.
Heat Your Socks Off! Love It!
By Kymberlee B
Escanaba, Michigan
Purchased 11/30/2020 |
Review Posted 01/12/2021
The heater is absolutely perfect! I have a 1000 sq for cottage and it heats the entire place. The only downside, it was damaged on one corner inside the box
Kymberlee B Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Easy To Use, Price, High Quality
Cons:
Was damaged inside the boxnot from freight
Love The Furnace.
By Stephen C
clyde, Michigan
Purchased 05/11/2020 |
Review Posted 10/21/2020
Easy to install, and really puts out the heat. I really like the furnace so far, the heating season has just started.
Stephen C Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
Pros:
Quiet, Easy To Use, Light Weight, Id Buy It Again
Cons:
Packaging, A lot of the sheet metal was bent, had to straighten.
Good price, well packaged.
By Ron H.
Gravette, Arkansas
Purchased 09/23/2020 |
Review Posted 10/05/2020
I normally don't give all 5 star reviews but. I purchased this unit and two of the accessory fans to replace an identical 30 year old unit. Everything shipped on time. The fans came regular carrier and arrived quite soon, the furnace came freight and was right on time. The product came in excessively sturdy packaging and arrived with no damage. eComfort price was well under any competitor and shipping for everything was free including the liftgate for the furnace. They also gave updates throughout the shipping process so there were no surprises.
I do recommend!
I do recommend!
Ron H. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Durable, Quiet, Price, Id Buy It Again
I have only had this heater for a week, but am very pleased thus
By Linda W.
Bella Vista, California
Purchased 02/14/2020 |
Review Posted 03/10/2020
I like the fan with two speeds.
Linda W. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
a very good product !
By Lois S.
Big Rapids, Michigan
Purchased 12/11/2019 |
Review Posted 01/20/2020
It does a great job heating. We got good advice from people who service Williams products. Everything went good installing.
Lois S. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
PRODUCT IS DOING ITS JOB.
By Edward D.
East Tawas, Michigan
Purchased 12/04/2019 |
Review Posted 01/17/2020
THE WALL FURNACE IS very efficient, warms the room to perfection, my Furnace installer liked how the Furnace was packaged ready for the install.
Edward D. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
4/5
Good furnace for small space
By Amin A.
Ann Arbor, Michigan
Purchased 12/05/2019 |
Review Posted 12/30/2019
Good furnace for small space or mobile home. It doesn't have a fan so heat will rise quickly but there is a fan accessory you can buy or if you have a ceiling fan that will help to disperse heat. I bought a back register kit to heat the bedroom located behind the furnace, which I highly suggest for any similar room situation. Overall, a good buy for the price point.
Amin A. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
4/5
5/5
