Williams Magnum High-Efficiency - 60K BTU - Gas Top-Vent Wall Furnace - 76% AFUE - Standing Pilot
Model:
6008832
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Ken, our Expert
Optional Accessories
16
$16.00
In-Stock
Model: 6702
$109.00
Factory-Direct
Model: 6701
$170.00
Factory-Direct
Model: P090542
$110.00
Factory-Direct
$109.00
Factory-Direct
$129.00
In-Stock
$110.00
Factory-Direct
$109.00
Model: 9940
$110.00
Factory-Direct
$110.00
Only 1 In-Stock
Model: P322016
$35.00
In-Stock
$110.00
Only 1 In-Stock
Model: 9812
$110.00
Factory-Direct
Model: 9824
$110.00
Model: 9836
$110.00
Factory-Direct
Model: 9929
$290.00
In-Stock
Features
- Counterflow Blower System
- The Forsaire furnace has a counterflow blower system that takes air from the ceiling and blows the warm air at the floor. This allows for the heat to be evenly distributed throughout the room.
- Safe Pilot Ignition
- With matchless pilot ignition, the guess work is taken out of lighting the furnace. By sealing the pilot and igniter away from dirt and debris, the electronic igniter lights the furnace safely and reliably.
- Vent Limit Safety Switch
- The vent limit safety switch is equipped on all Forsaire furnaces. This turns off the unit in case the vent is blocked, protecting your family from carbon monoxide and fires.
- Optional Multi-room Heating
- Supply an adjacent room with heat using the optional rear kit.
Requiring less than one square foot for installation, the Williams Forsaire High-Efficiency wall furnace can be surface mounted or recessed into a stud bay for even more space savings. Simply place it where you want it and vent it vertically through the ceiling and roof. Whether recessed into the wall or surface mounted, the soft-white powder coated finish provides a discrete durable finish that blends into any home's decor.
Product Note
A thermostat does not come included with this unit and is required. The Williams P322016 thermostat is compatible and can be found under the "Accessories" tab. Alternatively, any standard millivolt thermostat can be used.
California residents see
Warning: This product can expose you to chemicals including Epichlorohydrin which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
6008832
Overview
Product Category
Furnace
UPC
0093909299309
General Information
Type
Gas Wall Furnace
Product Line
Forsaire
Product Category
Furnace
Fuel Type
Fuel Type
To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
Natural Gas
Vent Type
Vent Type
Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
Chimney Vent
Modulating/Staging
Modulating/Staging
Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control. Learn More
Single Stage
Blower Motor Type
Single Speed
Mount Type
Wall
Gas Conversion Kit
Available
Performance
AFUE
AFUE
AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace. Learn More
76 %
Heating BTU
60000
High Fire Input
60000 BTU
High Fire Output
45500 BTU
Maximum Air Flow
440 CFM
Electrical Data
Minimum Circuit Ampacity
3 Amps
Dimensions
Flue Connection Size
4 Inches
Gas Connection Size
1/2 Inch
Product Height
80 1/4 Inches
Product Width
14 1/8 Inches
Product Depth
12 Inches
Product Weight
111 Pounds
Shipping Weight
121 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
Heat Exchanger Warranty
10 Years
Reviews
(26)
Williams 6008832 Reviews & Ratings
Customer Photos and Videos
Customer Rating
4.73
(26 Ratings)
94% recommend this product
5
(19)
(19)4(7)
(7)3(0)
(0)2(0)
(0)1(0)
(0)Install
By Michael B
Tennessee
Review Posted 02/22/2024
Looks great installed. After install unit wouldn’t start . Unit started smoking from transformer. We found the transformer wire pinched behind some metal grounded out. Had to replace the transformer on install. But after we replaced it works great.
Michael B Recommends This
Was this review helpful?
Rating Breakdown
5/5
4/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Wall Heater
By Larry B
Idaho
Purchased 11/22/2022 |
Review Posted 01/05/2024
Unit is absolutely fantastic
Larry B Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
I39d Buy It Again
Cons:
None
Works Like A Charm!
By Jimel
Oregon
Purchased 11/26/2017 |
Review Posted 03/27/2023
I bought this unit to replace the original wall furnace, vintage 1965. It fit perfectly, but it's not as tall as the old one, so I had to refinish the newly-exposed space above it. I also cut a hole in the floor under it and installed a flow-actuated one-way flap, so the unit would draw combustion air from under the house instead of taking indoor air. That has worked out perfectly, and I'm totally pleased. I just wish I had purchased a furnace with instant-on ignition instead of a pilot light, because the pilot keeps consuming gas. My solution: I shut it down after the heating season.
Jimel Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
5/5
5/5
Pros:
Easy To Use, I'd Buy It Again, High Quality, Quiet
Looks Good
By Timothy I
Iowa
Review Posted 09/29/2022
Good looks, quiet and puts out a ton of heat.
Timothy I Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, Id Buy It Again
Great Seller
By Rodney M
Iona, Idaho
Purchased 12/08/2020 |
Review Posted 12/30/2020
Easy install complete assembly, working great.
Rodney M Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Id Buy It Again, Easy To Use, Price, Reliable
Good quality unit
By Cynthia W.
Ault, Colorado
Purchased 06/10/2020 |
Review Posted 10/10/2020
This was a quality made unit. Nice finish, Solid color and light weight to handle. It looks great and works well.
Cynthia W. Recommends This
Was this review helpful?
Rating Breakdown
4/5
5/5
5/5
4/5
Pros:
Id Buy It Again, Easy To Use, High Quality, Easy to install
a very good product !
By Lois S.
Big Rapids, Michigan
Purchased 12/11/2019 |
Review Posted 01/20/2020
It does a great job heating. We got good advice from people who service Williams products. Everything went good installing.
Lois S. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Great Heater
By Anthony B
Hugo, Colorado
Purchased 11/09/2019 |
Review Posted 12/02/2019
Heater worked fine right out of the box
Anthony B Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
5/5
4/5
Pros:
Id Buy It Again
Happy so far.
By Ben S
Rockvale, Colorado
Purchased 01/03/2019 |
Review Posted 03/09/2019
I live in a rural Colorado (dirt road town). My 'new' 1890 built home had 3 sources of heat when I moved in, none of which worked. My plumber was able to use an old outlet (roof vented) to put this furnace in. The home has 70 year old windows (to soon be replaced). This furnace has been very comforting in the 45 winter mountain day's I've owned it. It seems well made and worth the very fair cost. Thank you!
Ben S Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
I'd Buy It Again, Price, Quiet, Light Weight
Love my wall furnace!
By Jill Z.
Saline, Michigan
Purchased 09/26/2018 |
Review Posted 02/13/2019
Easy install and generates nice heat! Love it!
Jill Z. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
