Williams - CV-B Series - 1.5 Ton - High Performance Vertical Fan Coil - Direct Expansion / Hydronic Heat - Right Hand - 120V/60Hz/1 Phase

Model:

V006DHB311R000

Write A Review
$1,284.30
Was $1,427.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 8-12 Weeks
synchrony card logo
$215 / Month
Suggested monthly payments with 6 month financing.
Williams - CV-B Series - 1.5 Ton - High Performance Vertical Fan Coil - Direct Expansion / Hydronic Heat - Right Hand - 120V/60Hz/1 Phase
Williams - CV-B Series - 1.5 Ton - High Performance Vertical Fan Coil - Direct Expansion / Hydronic Heat - Right Hand - 120V/60Hz/1 Phase
Model: V006DHB311R000
$1,284.30
Was $1,427.00
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Features

    Williams, a leading HVAC solutions provider, has been delivering quality heating and cooling solutions since 1916. With a commitment to innovation and quality, Williams offers a wide range of products including gas-fired heating, gravity wall heating, and fan coils. Williams manufactures their products using state-of-the-art machinery and adhering to the highest safety standards. With a long-standing reputation for excellence Williams is dedicated to providing industry-leading products and exceptional customer service for both residential and commercial applications. The CV-B is a high performance vertical fan coil with a bottom return, suitable for floor mounted or hideaway installations. It is furred into walls or closets with a ducted discharge for easy servicing. The unit comes with a coil, blower assembly, and drain pan, all housed in a galvanized steel cabinet with neoprene fiberglass insulation. A one inch supply duct flange is included on the top panel. This fan coil uses a DX coil also known as direct expansion coil. It cools air by evaporating refrigerant. The liquid-vapor mixture enters the coil, cools the air, and leaves as a gas. This fan coil also offers a dedicated right hand connection to provide a larger space for valve packages and controls.
  • Quality Insulation and Materials
  • Features heavy gauge cold rolled steel cabinet with 3.35 PCF density 1/2" fiberglass insulation and 1/2" OD copper coils, tested at 350 PSIG high pressure.
  • High-Pressure Tested
  • Coils are made of copper tube with aluminum fins, pressure tested at 350 PSI for reliability and performance.
  • Salt-Spray Tested Drain Pan
  • Galvanized drain pan with epoxy powder coating, subjected to a 650-hour salt spray test for corrosion resistance.
  • Efficient Motor
  • Three-speed PSC motor with quick connect plug for easy installation and operation.
  • Air Duct Openings
  • One inch reinforced duct collar on return and supply air openings.
  • Factory-Wired
  • Controls and motors are factory wired and terminated for a single point power supply, ensuring easy setup.
California residents see
Warning: This product can expose you to chemicals including Epichlorohydrin which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

V006DHB311R000
specs product image PID-153228
General Information
Type
Fan Coil
Product Line
CV-B Series
Product Category
Hydronic Air Handler
Refrigerant Type
R410A
Configuration Learn More
Configuration
Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.
Vertical
UPC
93909010560
Performance
Capacity Learn More
Capacity
Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.
1.5 Tons
Nominal Minimum Cooling Capacity
17850 BTU
Nominal Maximum Cooling Capacity
17850 BTU
Maximum Air Flow
607 CFM
Maximum Flow Rate
4.5 GPM
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Cold Water Inlet
1/2 Inch
Hot Water Inlet
1/2 Inch
Product Height
57 5/8 Inches
Product Width
20 1/4 Inches
Product Depth
14 1/4 Inches
Product Weight
125 Pounds
Shipping Weight
173 Pounds
Certifications
ETL Listed
Yes
UL Listed
Yes
AHRI Certified
Yes
ASTM Certified
Yes
NFPA Rated Learn More
NFPA Rated
The National Fire Protection Association has developed a system for indicating the health, flammability and reactivity hazards of some chemicals.
Yes
Warranty Information
Warranty Learn More
Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
1 Year
