Fantech SER260D
Fantech SER260D
Hover to zoom
1 Of 5

Fantech SER - 239 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 8" Duct - Exhaust

Model:

SER260D

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Fantech SER - 239 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 8
Fantech SER - 239 CFM - Energy Recovery Ventilator (ERV) - Side Ports - 8" Duct - Exhaust
Model: SER260D
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

eComfort expert image
Expert Recommended Accessories Selected by Ken, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

    The Fantech SER 3204D Energy Recovery Ventilator (ERV) is a 239 CFM energy recovery ventilator with side ports and exhaust defrost capabilities. The SER 260D is a 120 volt unit designed with 4 ports with 8" ducts and is suitable for very large residential or small commercial applications. ERVs make your heating and cooling systems more efficient by transferring heat and humidity between fresh and stale air during ventilation. Its compact size and wall bracket make this ERV easy to mount. The SER 260D Energy Recovery Ventilator (ERV) features an enthalpic core, washable electrostatic filters, and four factory-balanced fans.
  • Energy Recovery Core
  • Two AHRI certified cores are made from water vapor transport durable polymer membrane that is highly permeable to humidity. This core is freeze tolerant and water washable.
  • Winter Guard
  • A built-in exhaust defrost system allows for consistent, reliable operation during the winter months.
  • Serviceability
  • The SER 260D's core, filters, fans and electrical panel can be accessed easily from access panels on either side of the unit. The core conveniently slides out with only 14" clearance.
  • Washable Electrostatic Filters
  • Electrostatic filters capture airborne particles traveling through the ventilator. Easily washable, these filters can be repeatedly reused before replacement.

Specifications

SER260D
specs product image PID-107414
Overview
Product Category
Energy Recovery Ventilators (ERVs)
General Information
Type
ERV
Product Line
SER
Product Category
Energy Recovery Ventilators (ERVs)
Defrost Type Learn More
Defrost Type
ERV and HRV units may periodically suffer from frost formation on the heat exchanger. Units have different methods of eliminating this frost.
Exhaust
Ports Quantity
4
Port Location
Side
Performance
Maximum Air Flow
239 CFM
Apparent Sensible Effectiveness
73 %
Minimum Air Flow
94 CFM
Total Recovery Efficiency
54 %
Electrical Data
Voltage
120 Volts
Phase
1
Frequency
60 Hz
Dimensions
Duct Connection
8 Inches
Product Height
20 1/2 Inches
Product Width
27 7/8 Inches
Product Depth
25 1/4 Inches
Product Weight
80 Pounds
Certifications
CSA Listed
Yes
Warranty Information
Parts Warranty Learn More
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Motor Warranty
7 Years
